17.5 Exception Trap

An exception trap is an interrupt that is requested when the illegal execution of an instruction takes
place. Therefore, an illegal opcode exception (ILGOP: Illegal Opcode Trap) is considered as an excep-
tion trap.

17.5.1 Illegal opcode definition

The illegal instruction has an opcode (bits 10 to 5) of 111111B, a sub-opcode (bits 26 to 23) of 0111B to
1111B, and a sub-opcode (bit 16) of 0B. An exception trap is generated when an instruction applicable
to this illegal instruction is executed.
Remark:
Caution:
(1) Operation
If an exception trap occurs, the CPU performs the following processing, and transfers control to
the handler routine.
<1> Saves the restored PC to DBPC.
<2> Saves the current PSW to DBPSW.
<3> Sets the NP, EP, and ID bits of the PSW.
<4> Sets the handler address (00000060H) corresponding to the exception trap to the PC, and
Figure 17-28 illustrates the processing of the exception trap.
Downloaded from Elcodis.com electronic components distributor
Chapter 17 Interrupt/Exception Processing Function
Figure 17-27: Illegal Opcode Definition
15 11 10
⋅ ⋅ ⋅ ⋅ ⋅
1 1 1 1 1
×: Arbitrary
Since it is possible to assign this instruction to an illegal opcode in the future, it is
recommended that it not be used.
transfers control.
User's Manual U16702EE3V2UD00
5 4 0 31 27 26
0 1
⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅ ⋅
1
1 1
23 22 16
1 1
⋅ ⋅ ⋅ ⋅ ⋅ ⋅
to
0
1 1
