Additional Software Options
Compute Box settings:
In case, more than one Compute Box is used within the same network, for identification purpose any user
specific name can be entered to the Display name.
EtherNet/IP scanner settings:
NOTE:
This is a special option of the EtherNet/IP connection for some robots.
In case when the robot is the Adapter and the Compute Box needs to be the Scanner the following addition
information is required for the communication:
• IP address to connect to - the robot IP address
• Origin-to-target instance id - refer to the robot's EtherNet/IP manual (Scanner mode)
• Target-to-origin instance id - refer to the robot's EtherNet/IP manual (Scanner mode)
• Configuration instance id - refer to the robot's EtherNet/IP manual (Scanner mode)
• Requested packet interval (ms) - RPI value in ms (minimum 4)
Check the checkbox and the Compute Box will try to automatically connect to the robot (via the given IP
address).
