CDD-562L/564 Demodulator with IP Module
Quick Start Guide

7.3.2 Set CDM-IP Modems to Router Mode Operation

Perform the following steps on Satellite Modems (CDM-IP) 1 and (CDM-IP) 2:
Step Description
1 Beginning with the CDM-IP 1 modem:
From the CLI Main Menu, select the Administration [A] submenu.
2 From the Administration submenu, select CDM-IP Working Mode [C].
3 Select [1] for Router Mode – Small Network Mode.
When the following prompt is displayed:
Changing Modem working mode requires system Reboot.
Do you want to continue(Y/N)[Enter :No]
Confirm, when prompted, by typing [y] (yes).
4 Allow CDM-IP to reboot then, from the CLI Main Menu select Interface Configuration [ I ].
5 From the Interface Configuration submenu, select Receive HDLC Channel Addresses [H].
6 From the Receive HDLC Channel Addresses submenu, select [1] for HDLC Addr 1.
When the following prompt is displayed:
Please enter a value for the HDLC Addr 1
Press ESC to abort
HDLC address [SMALL NETWORK] in hex <0x1 - 0xFE, enter = 0001>:
Enter [1] to set HDLC Addr 1 to 0x01.
7 Continuing to the CDM-IP 2 modem:
For CDM-IP 2, repeat Steps 1-6 – except – for Step 6, set HDLC Addr 1 to 0x02.
HDLC Addr 1 will display as 0x0001, although only the last two digits are used in
Small Network Mode, allowing up to 254 separate HDLC addresses.
7–7
Revision 2
MN/CDD564L.IOM
