Comtech EF Data CDD-562L Installation And Operation Manual page 227

CDD-562L/564 Demodulator with IP Module
Appendix D
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier)
Downlink Route All DRM= 1 byte, 0 or 1
Multicast
EasyConnect EMO= 1 byte, value of
Multicast Option 0 or 1
Header HRA= 3 bytes
Compression
Refresh rate – All
Others
Header HRR= 3 bytes
Compression
Refresh rate –
UDP/RTP1
Header HRU= 3 bytes
Compression
Refresh rate –UDP
IGMP IGE= 1 byte, value of
enable/disable 0 or 1
Payload PRA= 3 bytes
Compression
Refresh rate
Query
Command or Query.
Enable/Disable Downlink Route All Multicast option, where:
0 = Disabled
1 = Enabled
Command or Query.
Valid only when in EasyConnect mode on CDM-570.
Enables or disables forwarding of multicast traffic while in EasyConnect mode, where:
0 = Disabled
1 = Enabled
Command or Query.
Restrictions: CDM-570 only
Refresh rate for all other streams, where Header compression refresh rate = 1 to 600;
Resolution=1 packet
Example: HRU =50
Command or Query.
Restrictions: CDM-570 only
Refresh rate for UDP/RTP1 streams, where Header compression refresh rate = 1 to 600,
Resolution=1 packet
Example: HRR=50
Command or Query.
Restrictions: CDM-570 only
Refresh rate for UDP only stream, where Header compression refresh rate = 1 to 600;
Resolution=1 packet
Example: HRU =50
Command or Query.
Enables or disables the IGMP feature, where:
0 = Disabled
1 = Enabled
Command or Query.
Restrictions: CDM-570 only
Refresh rate for all other streams, where Payload compression refresh rate = 1 to 600;
Resolution=1 packet
Example: PRU =50
Description of Arguments
D–11
Revision 2
MN/CDD564L.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
DRM= DRM? DRM=x
DRM! x – 0 or 1.
EMO = EMO? EMO=x
EMO! (see Description of Arguments)
HRA = HRA? HRA=xxx
HRA! (see Description of Arguments)
HRR = HRR? HRR=xxx
HRR! (see Description of Arguments)
HRU = HRU? HRU=xxx
HRU! (see Description of Arguments)
IGE = IGE? IGE=x
IGE! (see Description of Arguments)
PRA = PRA? PRA=xxx
PRA! (see Description of Arguments)
