CDD-562L/564 Demodulator with IP Module
Appendix D
D.4.1.8 Statistics Commands and Queries
D.4.1.8.1 Wan Stats
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier)
WAN RX: None 10 bytes,
Statistics Numerical
WAN TX: None 10 bytes,
Statistics Numerical
WAN Stats WSC= 1Byte
Clear Numerical
Query
Query only.
Displays all WAN Receive Statistics.
WAN Rx Bad Address Count
WAN Rx Pkt Proc CRC Errors
WAN Rx Abort/Oclet Errors
WAN Rx Overrun Errors
WAN Rx HDLC CRC Errors
WAN Rx HDLC Payload Byte Count
WAN Rx HDLC Header Byte Count
WAN Rx HDLC Packet Count
WAN Rx Invalid FlowID Errors
WAN Rx SAR Re-Assemble Errors
WAN Rx Header Decomp errors
WAN Rx Memory Alignment Errors
WAN Rx Bad CRC Errors
Query only.
Displays all WAN Transmit Statistics.
WAN Tx Error – No Route
WAN Tx Error – Packet Start
WAN Tx Error – Packet Front Length
WAN Tx Error – Packet End Length
WAN Tx Packet Invalid Length
WAN Tx Packet Dropped – Sat Overdriven
WAN Tx HDLC Header Byte Count
WAN Tx HDLC Payload Count
WAN Tx HDLC Packet Count
WAN Tx Utilization
Ethernet Traffic Destined to WAN
Actual Satellite Traffic (kbps)
Percentage of WAN Bandwidth Saved
Command only.
Set to '1' to clear all WAN Statistics – clears both Transmit & Receive Stats.
Description of Arguments
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)chr(10)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)
[ 0]chr(13)chr(10)
D–27
Revision 2
MN/CDD564L.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
SRT! SRT? Text display of all
WAN/Satellite Transmit
Statistics.
\r =CR = 0x0D
\n = Newline = 0x0A
STT! STT? Text display of all
WAN/Satellite Transmit
Statistics.
\r =CR = 0x0D
\n = Newline = 0x0A
WSC= N/A WSC=
Clear WAN Stats.
