CDD-562L/564 Demodulator with IP Module
Introduction
1.4.2

Low Noise Block Converter (LNB) Support (CDD-564L only)

Parameters
LNB Voltage
10 MHz Reference
Power Level
1.4.3

Environmental and Physical

Parameters
Temperature
Power Supply
Power Consumption
Fuse
Physical Dimensions
Weight
Agency Approvals
1.4.4

Network Protocols

Protocols
RFC 768 - UDP
RFC 791-IP
RFC 792 – ICMP
RFC 793 – TCP
RFC 826 - ARP
RFC 856 - Telnet
RFC 862 – Ping
RFC 894 – IP
RFC 959 – FTP
RFC 1112 – IP Multicast
RFC 1213 –SNMP MIB II
RFC 1812 – IPv4 Routers
Specifications
+13 volts, +18 volts, and +24 volts DC or OFF at 500 mA max per Rx input
-3 dBm ± 3 dB via Rx center conductor
Selectable ON or OFF per Rx input
Specifications
Operating
32 to 122°F (0 to 50°C)
Storage
-13 to 185°F (-25 to 85°C)
100 to 240 volts AC, 50/60 Hz
Optional: 48 VDC input (38 to 60)
75 W typical (140 W max – powering 4 LNBs)
120/230 VAC: T3, 15A, slow-blow 20 mm
48VDC (38 to 60 VDC): T8.0A, slow-blow 20 mm
1RU high x 19 inches wide x 16 inches deep
( 43.8 mm h x 482.6 mm w x 406 mm d)
7 lbs (3.2 kg)
CE Mark
FCC Part 15, Class B
RFC 2045 - MIME
RFC 2236 – IGMP v2
RFC 2474 – DS Field
RFC 2475 - ADS
RFC 2578 - SMI
RFC 2597 – PHB Group
RFC 2598 - PHB
RFC 2616 - HTTP
RFC 2821 - SMTP
RFC 3412 - SNMP
RFC 3416 – SNMPv2
RFC 3418 – SNMP MIB
1–14
Revision 2
MN/CDD564L.IOM
