CDD-562L/564 Demodulator with IP Module
Appendix D
D.5

Param Files

Param File Tag
SYS_WORKING_MODE
EASYCON_MCAST_MODE
HDR_REFRESH_UDP_RTP1
HDR_REFRESH_UDP
HDR_REFRESH_ALL_OTHERS
PAYLOAD_REFRESH
TELNET_TIMEOUT
QOSMODE
DYNBUF_LATENCY
Rt#0 .... Rt#nnn
ROUTE_HDLC_ADDR_SAVE
DHCP_RELAY_IP_ADDR
REDUNDANCY_ACTIVE
BASE_BOOT_IMAGE
UPGRADE_SLOT
BLINDLOAD_MCAST_ADDR
Values Associated with Parameter
Router Mode
Easy Connect Mode
Enabled
Disabled
DeCIMal Value of 1...600
DeCIMal Value of 1...600
DeCIMal Value of 1...600
DeCIMal Value of 1...600
DeCIMal Value of 1...60 Minutes
Rule-Max/Pri Mode
Rule-Min/Max Mode
DiffServ Mode
DeCIMal value of 200 to 5000 mSec.
Route table entries Rt#0 is the first entry and can go upto 256 entries.
[No need to read this from param file, use RTG]
Corresponding HDLC Addresses for Ethernet Sat entries. [No need to read this from param file, use RTG]
DHCP Server IP Address. Possible values are:
NOT-DEFINED – When the parameter not set.
10.20.30.40 – When a DHCP Server IP Address is set.
Enabled
Disabled
Latest
Image 1
Image 2
Oldest
Image 1
Image 2
NOT-DEFINED when ip_addr is 0
Valid multicast IP address like 239.4.5.6
