CDD-562L/564 Demodulator with IP Module
Appendix D
D.4.1.8.4 QoS Stats
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier)
Clear All QoS QSA= QSA=x
Queue Statistics 1 – Clear all
stats
Quality of Service QSC=xx xx – QoS rule
Stats Clear xx=QoS rule index for which
index to clear stats.
Quality of Service N/A String of QoS
Statistics Get Stats
Query
Command only.
Set QSA=1 to clear all QoS queue statistics. Also clears the default queue stats.
Command only.
Clears the QoS statistics for a specified queue.
To clear default queue stats use '0'.
Examples:
<1/QSC=0 will clear default queue stats
<1/QSC=5 will clear stats of rule-5.
Note: The command can be issued only on active/configured queue.
Query only.
Displays the QoS queue statistics of all active queues, in the form:
nnn|pp|aaaaaaaaaa|bbbbb|cccccccccc|dddddddddd|eeeeeeeeee|fffff|ggggg|hhhhh|iiii
where:
n = QoS Rule Number
p = Protocol number [Refer to QSR]
a = Sent Packets
b = Pkts per Second
c = Sent Bytes
d = Dropped Packets
e = Dropped Bytes
f = Current Transmit Rate [Kbps]
g = Average Transmit Rate [Kbps]
h = Maximum Transmit Rate [ Kbps]
I = Active Flow count associated with this QoS Queue.
Example: >0001/QST=
0| 19| 0| 0|
1| 0| 0| 0|
Description of Arguments
0| 0| 0| 0| 0| 0| 0chr(13)
0| 0| 0| 0| 0| 0| 0chr(13)
D–31
Revision 2
MN/CDD564L.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
QSA= None QSA=x
QSA! (see Description of Arguments)
QSC= None QSC=xx
QSC! (see Description of Arguments)
QST! QST? QST=sssssssss...
String displaying QoS stats of
all active queues.
\r – CR – 0x0D
\n – Newline – 0x0A
