CDD-562L/564 Demodulator with IP Module
Quick Start Guide

7.3.4 Set IP Address(es)

Step Task
1 From the CLI Main Menu, select Network Interface Configuration submenu [ I ].
2 From the Interface Configuration Menu, select Ethernet Interface submenu [E].
3 Select Ethernet IP Addresses [ I ], then set the addresses as follows:
•
•
•
4 Set Ethernet Subnet MaskSubnet Prefix Length [M] to 24.

7.3.5 Set IP Stack DES Select Key to ClearRoute Table

First, perform the following steps on Satellite Modem (CDM-IP) 1:
Step Task
1 From the CLI Main Menu, select the Route Table [R] submenu.
2 Enter '1' to configure the first route.
3 Enter a suitable name (e.g., 'test').
4 Set IP Address to '172.17.10.0'.
5 Set Number of Subnet Bits to '24'.
For Interface to which route is destined to <E-Ethernet S-Satellite Enter : S>
6
select 'S'.
For HDLC address [SMALL NETWORK] in hex <0x1 - 0xFE, enter = 0000>:
7
select '2'.
8 Per this example, the CDM-IP 1 Route Table should now display the following:
Route Name
Route001...[test 172.17.10.0/24
9 Go to "Per Route" by pressing [E], then disable 'HdrCompression', 'PayloadCompression' and
'3xDES' by selecting 'No' ('Clear' for 3xDES) for each of these choices.
Next, perform the following steps on Satellite Modem (CDM-IP) 2:
Step Task
1 From the CLI Main Menu, select the Route Table [R] submenu.
CDM-IP 1 to 172.16.10.1
CDD-56X to 172.16.10.2
CDM-IP 2 to 172.17.10.1
Dest IP/SNet Bits Next Hop MultiCast State
0x2
7–9
Revision 2
MN/CDD564L.IOM
N/A toSat]..1
