CDD-562L/564 Demodulator with IP Module
Appendix D
Param File Tag
ETHER_SPEED_MODE
ETHER_IP_SNET
HDLC_ADDR_MODE
QOSC
QOSCDEFR
DIFFSSV#0 ... DIFFSSV#11
IGMP_QRYP
IGMP_MXRT
IGMP_MRP
IGMP_QUERIES
IGMP_ROUTERALERT_OPT
IGMP_VERSION2
Values Associated with Parameter
Auto
10 MB/sec Half Duplex
100 MB/sec Half Duplex
10 MB/sec Full Duplex
100 MB/sec Full Duplex
IP Address in the format 192.168.1.50/24
Small Network Mode
Large Network Mode
Point-To-Point Mode
If there are no QoS rules configured, (or) system is not in Max-Pri (or) Min-Max mode, then param file will not have an entry for QOSC.
Otherwise, the rules will be in the following format.
QOSC### = SrcIP/Mask DstIP/Mask
QOSC#1 = ***/* ***/*
QOSC#2 = 11.12.13.14/32 22.22.33.44/32
Where
spm – source port min; spM – source port Max; dpm – Destination port min; dpM – Destination port Max
mxB – Max bandwidth in kbps; mb – minimum bandwidth in kbps [Total aggregate min bandwidth of all the qos rules should be less than
the Tx-Data rate of the system.]
P – Priority; W – WRED; F – Filter; [Y – Yes, N – No]
The default rule always exists in the system and in param file, but not meaningful if QoS mode is DiffServ. The format is
QOSC### = SrcIP/Mask DstIP/Mask PROT spm spM dpm dpM mxB mb P W F
QOSCDEFR#0 = ***/* ***/*
The DiffServ rules are meaningful only when QoS mode is DiffServ. Otherwise, these parameters can be discarded. The format is as follows.
The first column is
DIFFSSV#0 = 0 99999
NOTE: Donot use this from PARAM file, instead use DTG? Command.
A deCIMal value of 1...600
A deCIMal value of 1...598
A deCIMal value of 1...30
Yes
No
Yes
No
V1
V2
D–35
PROT spm spM dpm dpM mxB mb P W F
RTP *** *** *** *** 22222 0
UDP 11111 22222 33333 44444 99999 0
ALL *** *** *** *** 99999 0 9 N N
