CDD-562L/564 Demodulator with IP Module
IP Module Ethernet Interface
•
IGMP support for Multicast
•
Static IP routing for unicast and multicast
•
Symmetric and/or asymmetric operation for maximum bandwidth efficiency
•
Point-to-Point or Point-to-Multipoint configuration
•
Interoperable with the CDM-570/570L with IP Module, CDM-IP550, and CDM-IP 300L
4.1.2

10/100 BaseT Ethernet Interface

In Router Mode operation, the 10/100BaseT Ethernet Interface is used for routing IP traffic
received over the satellite to another device on the local LAN, and for monitor and control
purposes.
4.1.3

Powerful Network Management

Local or remote management of all demodulator and IP Module functions is available via SNMP,
Telnet, or HTTP. The demodulator may be configured, operated and monitored using any of the
following methods:
User Interface
SNMP
Telnet
Serial Command Line
Interface (CLI)
Web Server
4.1.4

Remote Firmware Update via FTP

Chapter 5. UPDATING FIRMWARE
The CDD-56X Satellite Demodulator with IP Module uses flash memory technology internally.
Firmware update archive files may be downloaded from the Internet to a user PC (from Comtech
EF Data's website), or obtained through Comtech EF Data Customer Support via e-mail or on CD
by standard mail delivery.
Once acquired from Comtech EF Data, new firmware can be uploaded from the user PC by File
Transfer Protocol (FTP) without opening the unit or having to be in the same physical location.
Connection
Local or remote – Ethernet via 10/100
BaseT Traffic interface
Local or remote – Ethernet via 10/100
BaseT Traffic interface
Local – Serial RS-232 via Console Port
Local or remote – Ethernet via 10/100
BaseT Traffic interface
4–2
MN/CDD564L.IOM
Demod IP MODULE
Functions Functions
ALL ALL
ALL ALL
ALL ALL
ALL ALL
Revision 2
Manual
Reference
Chapter 6
Chapter 6
Chapter 8
Chapter 9
