CDD-562L/564 Demodulator with IP Module
Appendix D
D.4.1

IP Commands and Queries

D.4.1.1 Admin Commands and Queries
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier)
Access List Delete ACD=x 1-byte numerical
1...4
Access List ACE= 1 byte, value of
Enforcement 0 or 1
Access Client List ACL= 18 bytes,
numerical
Administrator ADP= 11 bytes
Password No spaces
allowed.
Administrator ADU= 11 bytes
UserName No spaces
allowed.
3xDES Decrypt Key DDK[1..8]= 48 bytes,
numerical
3xDES Encrypt Key DEK[1..8]= 48 bytes,
numerical
Query
Command only.
Deletes the specified access list entry from the access list table in the form <1/ACD=x,
where x is value of 1...4
Command or Query.
Enables or disables access list enforcement, where:
0 = Disabled
1 = Enabled
Command or Query.
Sets the Access list entry, which contains a subnet and mask. Once access list is enabled,
only devices from the allowed ranges are allowed to communicate with the modem, in the
form xxx.xxx.xxx.xxx/yy, where:
xxx.xxx.xxx.xxx is the IP address, and yy is the network prefix (0-31)
Returns 000.000.000.000/32 when a particular Access Client is not configured.
Example: <1/ACL[1]=010.006.030.001.24
Command or Query.
Changes the administrator password.
Example: ADP=comtech
Command or Query.
Changes the administrator username.
Example: ADU=comtech
Note: To activate the new user name, ADP must be issued immediately after ADU. Then
query ADU? to see new value.
Command or Query.
3xDES decrypt key, where all are HexadeCIMal digits. [0...F], a total of 48 Hex digits.
Example: DDK:0=222222222222222244444444444444446666666666666666
Command or Query.
3xDES encrypt key [192-Bit], where all are HexadeCIMal digits. [0...F], a total of 48 Hex
digits.
Example: DEK[1]=222222222222222244444444444444446666666666666666
Description of Arguments
D–10
Revision 2
MN/CDD564L.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
ACD= N/A ACD=x [1..4]
ACD! (see Description of Arguments)
ACE = ACE? ACE=x
ACE! (see Description of Arguments)
ACL = ACL? ACL=xxx.xxx.xxx.xxx.yy (see
ACL! Description of Arguments)
ADP = ADP? ADP=xxxxxxxxxxx
ADP! (see Description of Arguments)
ADU = ADU? ADU=xxxxxxxxxxx
ADU! (see Description of Arguments)
DDK = DDK[1..8]? DDK=x [1..48]
DDK! (see Description of Arguments)
DEK = DEK[1..8]? DEK=x [1..48]
DEK! (see Description of Arguments)
