Installation and Startup
The tools needed to install the KT/6228-2 (4") or KT/6228-3 (10") Rear-Mounting
Support Brackets Kit are as follows:
•
A medium Phillips™ screwdriver
•
A 5/32-inch SAE Allen™ Wrench
•
An adjustable Crescent™ wrench.
To install the kit (
Step Task
Use the #10 flat washers, #10 split washers, and #10 hex nuts to secure the #10 shoulder screws
1
to the unit chassis through the rear right and left side mounting slots.
Use the #10 rack bracket bolts to install the rear support brackets onto the rack enclosure
2
threaded rear mounting rails.
Mount the unit into the rack enclosure. Ensure that the shoulders of the #10 shoulder screws
3
properly engage into the rear support bracket slots.
2.3

Initial Configuration

There are no internal jumpers to configure, no interface cards to install, and no other options to
install—all configurations are carried out entirely via firmware.
The unit will ship with a default 64 kbps, QPSK, Rate 3/4 configuration; the unit should first be
further configured locally, using the EIA-232 Console Interface.
Note: The auto-sensing AC power supply does not require any adjustments. Simply plug in the
supplied line cord, and turn on the switch on the rear panel.
2.4

Connecting External Cables

Once the desired configuration settings have been made, proceed to connect all external cables to
the connectors outlined in the next chapter (Chapter 3. REAR PANEL CONNECTORS
PINOUTS). Should difficulties occur, call Comtech EF Data Customer Support for assistance.
):
