Comtech EF Data CDD-562L Installation And Operation Manual page 237

CDD-562L/564 Demodulator with IP Module
Appendix D
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier)
IGMP View Table None String value
IGMP Server: IGMP IMR= IMR=xxx
Max Resp. Time Where xxx is
value of 1 to 598
IGMP Server: INM= 2 bytes,
Number of Missed Numerical 1..30
Responses
IGMP Client: IRI= 2 bytes 0..25
Unsolicated Report
Internval
IGMP IRO= 1 byte, 0 or 1
Client Router Alert
Option for V1
IGMP Client IRQ= 1 byte, 0 or 1
Recognize Queries
Query
Query only.
Displays the IGMP table with different states. To see the entries, the system should have
the IGMP feature enabled, and should be properly configured to forward IGMP packets.
See WEB interface for proper table format.
Note: Not yet supported in 1.5.3 Release, will be available in next release.
Command or Query.
Sets the Maximum response time for the IGMP Query in seconds. Should always be 2 less
than query period. The range is 1 to (IGQ – 2). If IGQ is at 30, then IMR can be set from 1
through 28.
Command or Query.
Number of missed responses before leaving the IGMP Group.
Configured from 1...30
Example: INM=15
Command or Query.
Sets the unsolicited Report Interval [Modem as Client], where:
Range = 1..25
Example: <1/IRI=14
Command or Query.
Enables/Disables Router Alert option for V1 Reports, where:
0 = No
1 = Yes
Example: IRO =0
Command or Query.
Enable/Disable Recognizing IGMP Queries, where:
0 = No
1 = Yes
Example: IRQ=0
Description of Arguments
D–21
Revision 2
MN/CDD564L.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
IGT= IGT? IGT=sssssss
IGT! Table of IP Addresses and their
state information.
IMR= IMR? IMR=xxx
IMR! xxx - value of 1 to 598.
INM = INM? INM =xxx
INM! (see Description of Arguments)
IRI = IRI? IRI =xxx
IRI! (see Description of Arguments)
IRO = IRO? IRO =xxx
IRO! (see Description of Arguments)
IRQ = IRQ? IRQ =xxx
IRQ! (see Description of Arguments)
