CDD-562L/564 Demodulator with IP Module
HTTP (Web Server) Interface
VLAN Brouter
In order for this feature to work, Header Compression must be purchased and
available.
The VLAN Brouter feature allows VLAN tagged packets to be forwarded when in Brouter mode.
•
VLAN Brouter Mode: Use the drop-down list to select this mode as Enabled or Disabled.
Note the following:
o This mode can be enabled only when one of the Router modes is enabled.
o When Managed Switch Mode is enabled, this feature is automatically disabled.
•
VLAN Brouter Next Hop MAC Address: When VLAN Brouter Mode is enabled, the user
may enter the Next Hop MAC Address, to which VLAN tagged packets are to be directed,
into this text field.
•
VLAN Filter: Use the drop-down list to set this feature as Enabled or Disabled.
•
VLAN Remote Mode: Use the drop-down list to select this mode as Enabled or Disabled.
•
VLAN ID1 through VLAN ID10: Enter a valid ID in the range of 0000 to 4095.
Click [Submit] to execute the changes made on this page.
