CDD-562L/564 Demodulator with IP Module
Updating Firmware
Step Task
3 Confirm availability of the firmware files in the temporary folder. There are a number of ways
the user may view the contents of the temporary folder on a Windows-based PC:
A. From the Windows Desktop:
•
Double-left-click the "temp" folder saved to the Windows Desktop.
•
Use Windows Explorer to locate, and then double-left-click the "temp" folder.
•
Use the 'Browse' window ([Start] > ...Run > [Browse]) to locate, and then double-
click the "c:\temp" folder.
B. Using Command-line:
•
Type "cd c:\temp" at the Command-line prompt to change to the temporary directory
created earlier using Command-line.
•
Type "dir" to list the files extracted to the temporary directory from the downloaded
archive file.
The firmware files have been successfully downloaded and are now available for transfer to the
CDD-56X.
