CDD-562L/564 Demodulator with IP Module
CDD-56X CLI and Telnet Operation
8.2 CLI Menu Pages
Interface Appearance – The remaining sections in this chapter show CLI pages as they appear
with the user-supplied HyperTerminal terminal emulator application. The appearance of this
interface may vary across individual user configurations. For this reason, a complete CLI window
is shown for the Main Menu page only.
The remainder of this chapter shows the selectable CLI pages. Functionality is explained in
tabulated format as follows:
•
Selection: This column lists the name of the function or command as it appears on the
menu page.
•
Entry: This column identifies the letter or number assigned as the keystroke/mnemonic
for execution of that function or command. Type this letter to execute; otherwise, where
the Entry column specifies [RO], this means that the pertinent menu selection is a read-
only feature.
•
Description: This column provides the detailed explanation for the selection. Where
applicable, command modifiers required to execute a specific action are also specified.
Common Interface Selections/field – The menu functions indicated here are common for all
primary and nested pages:
Selection
Demod Select
Save Parameters to permanent
storage
Exit
Entry Description
Z Selects the active receive channel to apply the configuration:
• CDD 564/564L has 4 Rx Channels
• CDD 562/562L has 2 Rx Channels.
S Allows user to permanently save the current configuration. This
configuration is then stored to flash memory and recalled for
subsequent operational sessions.
X Allows user to exit the current menu and return to its parent menu.
