CDD-562L/564 Demodulator with IP Module
CDD-56X CLI and Telnet Operation

8.2.8 Operations and Maintenance page

Access the Operations and Maintenance page from the Main Menu page.
This page contains the following unique selections/fields:
Selection
Unit Up Time
Unit Information
Boot From
Upgrade To
Codecast Multicast Address
Entry Description
[RO] Displays the elapsed time the unit has been running continuously
since its last reboot.
I Opens the Unit Information page, which provides details about the
unit's current operational firmware.
B Determines which version of the IP Module firmware (including
Application, FPGA, and FFPGA) will be loaded upon boot-up. The
possible options are:
0 (Latest) – Boots the newest firmware package based upon date.
1 (Image1) – Boots the firmware package loaded into the first slot
in permanent storage.
2 (Image2) – Boots the firmware package loaded into the second
slot in permanent storage.
U Determines which installed firmware package (including Application,
FPGA, and FFPGA) that the IP Module will overwrite when upgrading
with a new firmware package. The possible options are:
0 (Oldest) – Overwrites the oldest firmware package based upon
date.
1 (Image1) – Overwrites the firmware package loaded into the first
slot in permanent storage.
2 (Image2) – Overwrites the firmware package loaded into the
second slot in permanent storage.
M Configures the IP Multicast Address for the Codecast protocol. The IP
Module has the ability to get the firmware updates installed on multiple
units using the Codecast protocol, making unit upgrades easy in
bigger networks.
8–39
Revision 2
MN/CDD564L.IOM
