Chapter 4. IP MODULE ETHERNET
4.1

Introduction

For information specific to CDD-56X IP Module operation when deployed in a
Vipersat system, please consult adjunct Comtech EF Data publication MN/22137
– Vipersat CDD-56X Series Satellite Network Demodulator Router User Guide.
The CDD-562X Satellite Demodulator's integral IP Module Ethernet Interface is intended for
closed network Single Channel Per Carrier (SCPC) links. It concentrates traffic from two or four
independent demodulators into a single Ethernet port, making it ideal for networked VSAT
applications. The CDD-56X can also be utilized in a Vipersat satellite bandwidth management
system.
4.1.1

Standard Features

•
10/100BaseT Ethernet Interface (RJ-45)
•
Powerful network management:
o SNMP with public and private MIB
o Telnet interface for remote product M & C
o Web Server interface for complete product management
o Console Port interface for local network management
•
Remote software/firmware upgrade via FTP
•
Configuration backup and restore via FTP
•
Event Logging to capture all IP Module activity
•
Detailed Statistics of IP traffic
INTERFACE
4–1
