CDD-562L/564 Demodulator with IP Module
Appendix D
Command Arguments for
Parameter (Instruction Command or
Type Code and Response to
Qualifier)
Route Table RTE RTE[1..256]=var
iable
Query
Command or Query.
In the form sssssssssssss|ddd.ddd.ddd.ddd/DD|i|nnn.nnn.nnn.nnn|hhhh|t|p|c|k|S
where:
s = Route Name up to 13 characters. It should be unique. Reusing of route names with
different index, will end up modifying the existing route.
d = Destination IP Address in xxx.xxx.xxx.xxx/yy where:
xxx.xxx.xxx.xxx is IP address and
yy – Subnet mask bits.
To mean 'Any IP Address' indicate it by ***.***.***.***/** format.
D = Destination Subnet Mask Bits.
i = Interface 1 – Sat and 0 – Ethernet
n = Next Hop IP Address in xxx.xxx.xxx.xxx format.
To be valid the next hop should be on the same subnet
as the router IP Address. This field will be all '*' for a 'SAT' directed route.
It means, for a route with valid HDLC address this field will be '***************'.
h = HDLC Addr in 4-digit hexadeCIMal number.
Valid range is 0x00 to 0xFE in Router-Small Network mode.
and 0x0000 to 0x7FFE for Router-Large Network mode.
This field will be all '*' for 'ETH' directed route, meaning if the route has a valid
next-hop, then this field is '****' [meaning HDLC Address is not Used.].
HDLC Address is not used in point-to-point mode, may default to '1'.
t = Header Compression 0 = No 1 = Yes.
p = Payload Compression 0 = No 1 = Yes.
c = DES Encryption 0 = No 1 = Yes.
k = DES Key to use 0 = Don't use any key
1 – 8 = use as mentioned, and
9 = Use Random key.
S = Multicast state 0 = None 1 = Eth-to-Sat
When called using an existing index, the command is treated as a "modify". Only new
routes can be added at the END of the list:
Example: RTN?
RTN=3
<1/rte[3]=rt3|239.111.102.222.32|0|192.168.001.022|00AB|0|0|1|5|3
Sat Directed Route:
>0001/RTE[1]=rt1|011.012.013.014/32|1|***.***.***.***|1111|0|0|0|0|0
Eth Directed Route:
>0001/RTE[4]=rt4|012.013.014.015/32|0|192.168.001.111|****|0|0|0|0|0
Note: To be able to set/get the route entries, the system should be in the routing. It may
return RTE! if system is in EasyConnect mode.
Description of Arguments
2 = Sat-to-Eth 3 = toBoth
D–26
Revision 2
MN/CDD564L.IOM
Query
Response to (Instruction
Response to Query
Command Code and
Qualifier)
RTE = RTE[1..256]? RTE[1..256] = xxx
RTE! (see Description of Arguments)
