CDD-562L/564 Demodulator with IP Module
Introduction
configuration of the unit. The unique, register-specific FAST Access Code that is purchased from
Comtech EF Data enables configuration of the available hardware.
FAST Accessible Options
Hardware options for basic demodulators can be ordered and installed either at the factory or in
the field. The operator can select options that can be activated easily in the field, depending on
the current hardware configuration of the demodulator. A unique access code enables
configuration of the available hardware.
As standard features, the demodulator is configured with an Integrated IP router compatible with
the optional IP Module/router available in the CDM-570/570L Satellite Modem, and Integrated
nd
2 Generation Turbo FEC compatible with the CDM-570/570L.
The following table shows the available FAST and FAST-accessible hardware options:
Option
Low-Rate Variable
QPSK
TPC Codec
IP Router
-48 VDC
Mid-Rate Variable
Full-Rate Variable
High-Rate Variable
3xDES Data Encryption
IP Header Compression
Payload Compression
8-PSK
16-QAM
Description and Comments
Data rate 16 kbps to 512 kbps
Modulation Type
Turbo Product Codec (IESS-315 compliant)
10/100 Base-T Interface
-48 VDC Prime Power Supply
Data rate 16 kbps to 2.048 Mbps
Data rate 16 kbps to 5.0 Mbps
Data rate 16 kbps to 9.98 Mbps
Uses NIST certified 3x core
Software Version 1.5.1 and later
Uses proprietary IP Header Compressions
Software Version 1.5.1 and later
Uses proprietary Payload Compressions
Software Version 1.5.1 and later
8-PSK Modulation
16-QAM Modulation
1–11
Revision 2
MN/CDD564L.IOM
Installation
Method
Base Unit
Standard
Standard
Standard
Hardware
FAST
FAST
FAST
FAST
FAST
FAST
FAST
FAST
