CDD-562L/564 Demodulator with IP Module
Ethernet-based Remote Product Management
6.5

HTTP (Web Server) Interface

A user-supplied web browser allows the full monitor and control (M&C) of the CDD-56X from
its HTTP Interface. The CDD-56X embedded web application is designed for, and works best
with, Microsoft's Internet Explorer Version 6.0 or higher.
The parameters featured on the individual web pages are described in Appendix D. CDM/CDD
NMCS PROTOCOL. For further details on using the HTTP Interface, see Chapter 9. HTTP
(WEB SERVER) INTERFACE.
6.5.1 HTTP (Web Server) Interface – Typical Operational Features
6.5.1.1 Interface Access
Type the CDD-56X IP Address (shown here as http://xxx.xxx.xxx.xxx) into the Address area of
the user-supplied web browser:
The Login window will appear, similar to the example shown
here, and the user is prompted to type a User name and
Password.
The Web Server Interface default user names and passwords
are as follows:
•
Admin
•
Read/Write
•
Read Only
Type the User Name and Password, and then click [OK].
Once the valid User Name and Password is accepted, the user
will see the CDD-56X Web Server Interface "splash" page,
as per the example shown to the right:
HTTP Login User Access Levels are further defined as follows:
Admin User
Full Access to
all web pages.
comtech/comtech
opcenter/1234
monitor/1234
Read/Write User
No Access to Admin web pages.
Full Access for all other web pages
Read Only User
No Access to Admin web pages.
View Only Access for all other web pages.
