CDD-562L/564 Demodulator with IP Module
HTTP (Web Server) Interface
9.3.3 Demod (Configure Demodulator) pages
The 'LNB' hyperlink is available only on the CDM-562L/564L HTTP Interface.
Click the Demod, Utilities, Status, Events, Statistics, or LNB hyperlink to continue.
9.3.3.1

Demod | Demod

The Rx Interface Types have highest priority and should be configured before
setting any other parameters.
Sect. 6.2.7.1 Configuration page in Chapter 8. CDD-56X CLI
OPERATION for detailed operational information.
Use this page on a per-demod basis to configure or review demodulator operating (Rx) parameters.
Demodulator
Enter an operational value for each of the following parameters:
•
Frequency
•
Eb/No Alarm Point
Figure 9-12. Demod | Demod page
•
Data Rate
•
Internal Reference Adjust
9–16
Revision 2
MN/CDD564L.IOM
TELNET
AND
•
Demod Acqusition Range
