Levelflex FMP51, FMP52, FMP54
Endress+Hauser
Accessory Description
Mounting bracket for the
electronics housing
A
B
Accessory Description
Extension rod / centering
HMP40
• can be used for:
FMP54
• Admissible temperature
at lower nozzle edge:
-40 to 150 °C
1
(-40 to 302 °F)
• Additional information:
SD01002F
1
2
3
010
A
M
P
S
U
1
2
020
A
122 (4.8)
158 (6.2)
Wall mounting
Pipe mounting
For the "Sensor remote" device version (see feature 060 of the product structure),
the mounting bracket is part of the delivery. If required, it can also be ordered as an
accessory (order code 71102216).
2 3
Nozzle height
Extension rod
Center washer
Approval:
A: Non-hazardous area
M: FM DIP Cl.II Div.1 Gr.E-G N.I., zone 21,22
P: CSA DIP Cl.II Div.1 Gr.G + coal dust N.I.
S: FM Cl.I, II, III Div.1 Gr.A-G N.I., zone 0,1,2,20,21,22
U: CSA Cl.I, II, III Div.1 Gr.A-G N.I., zone 0,1,2
1: ATEX II 1G
2: ATEX II 1D
Extension rod; nozzle height:
Accessories
B
140 (5.5)
175 (6.9)
Ø 42 ... 60
mm (inch)
(1-1/4 ... 2)
A0014793
A0013597
