Fmp51: Dimensions Of Process Connection (G1½,Npt1½,Flange) And Probe - Endress+Hauser Levelflex FMP51 Operating Instructions Manual

Levelflex FMP51, FMP52, FMP54
C
ø59.35
(ø2.34)
SW55
AF55
G1
½
J
SW10
AF10
ø4
(ø .16) 0
ø22
(ø .87) 0
M14
mm (in)
(ø2.95)
Endress+Hauser
6.1.4 FMP51: Dimensions of process connection
(G1½,NPT1½,flange) and probe
D
ø59.35
(ø2.34)
SW55
AF55
NPT 1
½
K
SW10
AF10
SW10
AF10
ø4
(ø0.16)
ø12
(ø0.47)
ø29
(ø1.14)
ø75
A Mounting bracket for probe design "Sensor remote" (Feature 600)
C Thread ISO228 G1-1/2 (Feature 100)
D Thread ANSI MNPT1-1/2 (Feature 100)
E Flange ANSI B16.5, EN1092-1, JIS B2220 (Feature 100)
J Rope probe 4mm or 1/6" (Feature 060)
K Rope probe 4mm or 1/6"; centering disk optional (Features 060 and 610)
L Rod probe 12mm or 1/2"; centering disk optional, see table below (Features 060 and 610)
M Rod probe 16 mm or 0.63in, 20" or 40" divisible; centering disk optional, see table below (Feature 060 and 610)
N Coax probe; AlloyC (Feature 060)
E
ø59.35
(ø2.34)
L M
SW14
AF14
ø16
(ø0.63)
SW14
AF14
SW14
AF14
Q Q
2.77 (0.11)
Q
122
(4.8)
r = 100 (4)
min
ø82.5
(ø3.25)
R
N
ø10 (0.4)
ø42.2 ø42.4
(ø .66)* 1 (ø .67) 1
Mounting
A
O
2 (0.08)
A0012756
29
