Levelflex FMP51, FMP52, FMP54
Endress+Hauser
060 Probe:
BD ..... inch, rod 0.63in 316L, 40 inch divisible
CA ..... mm, rod 16mm PFA>316L
CB ..... inch, rod 0.63in PFA>316L
LA ..... mm, rope 4mm 316
LB ..... inch, rope 1/6" 316
MB ..... mm, rope 4mm 316, max 300mm nozzle height, center rod
MD ..... inch, rope 1/6" 316, max 12inch nozzle height, center rod
OA ..... mm, rope 4mm PFA>316, max 150mm
OB ..... mm, rope 4mm PFA>316, max 300mm
OC ..... inch, rope 1/6" PFA>316, max 6inch
OD ..... inch, rope 1/6" PFA>316, max 12inch
UA ..... mm, coax 316L
UB ..... inch, coax 316L
UC ..... mm, coax AlloyC
UD ..... inch, coax AlloyC
YY Special version, TSP-no. to be sepc.
090 Seal:
A4 Viton, -30...150°C
B3 EPDM, -40...120°C
C3 Kalrez, -20...200°C; saturated steam max. 150°C
D1 Graphite, -196...280°C (XT); saturated steam max. 200°C
D2 Graphite, -196...450°C (HT)
Y9 Special version, TSP-no. to be sepc.
100 Process connection:
AAJ 2" 300/600lbs RF, 316/316L flange ANSI B16.5 (CRN)
ABJ 3" 300/600lbs RF, 316/316L flange ANSI B16.5 (CRN)
AEJ 1-1/2" 150lbs RF, 316/316L flange ANSI B16.5 (CRN)
AEK 1-1/2" 150lbs, PTFE>316/316L flange ANSI B16.5 (CRN)
AEM 1-1/2" 150lbs, AlloyC>316/316L flange ANSI B16.5 (CRN)
AFJ 2" 150lbs RF, 316/316L flange ANSI B16.5 (CRN)
AFK 2" 150lbs, PTFE>316/316L flange ANSI B16.5 (CRN)
AFM 2" 150lbs, AlloyC>316/316L flange ANSI B16.5 (CRN)
AGJ 3" 150lbs RF, 316/316L flange ANSI B16.5 (CRN)
AGK 3" 150lbs, PTFE>316/316L flange ANSI B16.5 (CRN)
AGM 3" 150lbs, AlloyC>316/316L flange ANSI B16.5 (CRN)
AHJ 4" 150lbs RF, 316/316L flange ANSI B16.5 (CRN)
AHK 4" 150lbs, PTFE>316/316L flange ANSI B16.5 (CRN)
AJJ 6" 150lbs RF, 316/316L flange ANSI B16.5 (CRN)
AJK 6" 150lbs, PTFE>316/316L flange ANSI B16.5 (CRN)
Incoming acceptance and product identification
FMP
51 52 54
x x
x
x
x x
x x
x
x
x
x
x
x
x x
x x
x
x
x x x
FMP
51 52 54
x
x
x
x
x
x x x
FMP
51 52 54
x
x
x
x
x
x x
x
x
x x
x
x
x x
x
x
x
