Operating options
User role Typical tasks
Operator Tasks in the ongoing process:
• Configuration of the display.
• Reading measuring values.
Maintenance Commissioning:
• Configuration of the measurement.
• Configuration of the measured value processing (scaling,
linearization, limit detection etc.).
• Configuration of the measured value output (analog and
digital communication interface).
Error handling
Expert Tasks which require detailed knowledge about the
instrument:
• Commissioning of measurements under demanding
conditions.
• Optimization of the measurement under demanding
conditions.
• Detailed configuration of the communication interface.
• Error diagnosis in diffcult cases.
66
8.2.2

Submenus and user roles

The submenus are designed for different user roles. A user role is defined by typical tasks within
the lifecycle of the device.
8.2.3

Locking the menu

Locking the menu via the locking switch (hardware locking)
The complete operating menu can be locked by the locking switch below the display and
operating module. In the locked state most parameter values can be read but not changed.
Submenu Content/Meaning
"Language" Defines the operating language.
"Display/Operation" Contains all parameters which are needed during the
ongoing process:
Configuration of the display (display values, display format,
display contrast ...).
"Setup" Contains all commissioning parameters:
• Setup parameters
When all these parameters have been assigned
appropriate values, the measured should be completely
configured in a standard application.
• "Advanced setup" submenu
Contains further submenus and parameters:
– to adapt the device to special measuring conditions.
– to process the measured value (scaling, linearization).
– to configure the signal output.
"Diagnostics" Contains all parameters needed to detect and analyze
operational errors.
• Diagnostics list
Contains up to 5 currently active error messages.
• Event logbook
Contains the 10 last messages (which are no longer
active).
• "Device info" submenu
Contains information needed to identify the device.
• "Measured values" submenu
Contains all current measured values.
• "Simulation" submenu
Used to simulate measured values or output values.
"Expert" Contains all parameters of the device (including those
which are already contained in one of the above
submenus). This menu is organized according to the
function blocks of the device:
• "System" submenu
Contains all general device parameters which do not
affect the measurement or the communication interface.
• "Sensor" submenu
Contains all parameters needed to configure the
measurement.
• "Output" submenu
Contains all parameters needed to configure the switch
output (PFS)
• "Communication" submenu
Contains all parameters needed to configure the digital
communication interface.
• "Diagnostics" submenu
Contains all parameters needed to detect and analyze
operational errors.
