Trouble shooting
86
Status signals
"Failure"
A device error is present. The measured value is no longer valid.
A0013956
"Function check"
The device is in service mode (e.g. during a simulation).
A0013959
"Out of specification"
The device is operated:
• Outside of its technical specifications (e.g. during startup or a cleaning)
A0013958
• Outside of the configuration carried out by the user (e.g. level outside configured span)
"Maintenance required"
Maintenance is required. The measured value is still valid.
A0013957
Status symbol (symbol for event level)
"Alarm" status
The measurement is interrupted. The signal outputs take on the defined alarm condition. A
diagnostic message is generated.
A0013961
"Warning" status
The device continues to measure. A diagnostic message is generated.
A0013962
Diagnostics event and event text
The fault can be identified using the diagnostics event. The event text helps you by providing
information about the fault. In addition, the corresponding symbol is displayed before the
diagnostics event.
Status symbol
Example
If two or more diagnostic messages are pending simultaneously, only the message with the
highest priority is shown. Additional pending diagnostic messages can be shown in the
Diagnostics list submenu
Past diagnostic messages that are no longer pending are shown in the Event logbook
submenu (Verweisziel existiert nicht, aber
Operating elements
Operating functions in menu, submenu
Plus key
Opens the message about the remedial measures.
A0013970
Enter key
Opens the operating menu.
A0013952
Diagnostics event
Status signal
¯
A0013962 A0013958
3-digit number
(Verweisziel existiert nicht, aber
@y.link.required='true').
Levelflex FMP51, FMP52, FMP54
Event number Event text
¯ ¯
441 Curr.output 1
@y.link.required='true').
