Mounting
R
mm (in)
28
6.1.3 FMP51: Dimensions of process connection (G¾,NPT¾) and
probe
F
SW7
AF7
ø4
(ø0.16)
M14
ø22 (ø .87) 0
A Mounting bracket for probe design "Sensor remote" (Feature 600)
B Thread ISO G3/4 or ANSI MNPT3/4 (Feature (100)
F Rope probe 4mm or 1/6" (Feature 060)
G Rope probe 4 mm or 1/6"; centering disk optional (Features 060 and 610)
H Rod probe 8mm or 1/3" (Feature 060)
I Coax probe (Feature 060)
LN Length of probe
R Reference point of the measurement
B
ø59.35
(ø2.34)
SW36
AF36
G
¾
NPT¾
G
SW7
AF7
ø4
ø8
(ø0.16)
(ø0.31)
ø29 (ø1.14)
ø75 (ø2.95)
Levelflex FMP51, FMP52, FMP54
122
(4.8)
r = 100 (4)
min
ø82.5
(ø3.25)
H I
SW7
AF7
A
ø10 (0.4)
ø22
(ø .87) 0
2 (0.08)
A0012645
