TI01001F/00/EN/19.15
71282391
Products
Technical Information
Levelflex FMP51, FMP52,
FMP54
Guided wave radar
Level and interface measurement in liquids
Application
• Rod, rope or coax probe
• Process connection: Starting 3/4" thread, flange or process connections for hygiene
requirements (Tri-Clamp, 11851)
• Temperature: –196 to +450 °C (–320 to +842 °F)
• Pressure: –1 to +400 bar (–14.5 to +5 800 psi)
• Maximum measuring range: Rod 10 m (33 ft); rope 45 m (148 ft); coax 6 m (20 ft)
• Accuracy: ±2 mm (±0.08 in)
• International explosion protection certificates; WHG; ship building approval; steam
boiler approval; EN10204-3.1
• Linearity protocol (3-point, 5-point)
Your benefits
• Reliable measurement even for changing product and process conditions
• HistoROM data management for easy commissioning, maintenance and
diagnostics
• Highest reliability due to Multi-Echo Tracking
• Hardware and software developed according to IEC 61508 (up to SIL3)
• Seamless integration into control or asset management systems
• Intuitive user interface in national languages
• Easy proof test for SIL and WHG
Solutions
Services

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Levelflex FMP51 and is the answer not in the manual?

Questions and answers

Related Manuals for Endress+Hauser Levelflex FMP51

Summary of Contents for Endress+Hauser Levelflex FMP51

  • Page 1 Products Solutions Services TI01001F/00/EN/19.15 71282391 Technical Information Levelflex FMP51, FMP52, FMP54 Guided wave radar Level and interface measurement in liquids Application • Rod, rope or coax probe • Process connection: Starting 3/4" thread, flange or process connections for hygiene requirements (Tri-Clamp, 11851) •...

  • Page 2: Table Of Contents

    Levelflex FMP51, FMP52, FMP54 Table of contents Important document information ....4 Electromagnetic compatibility (EMC) ....
  • Page 3 Levelflex FMP51, FMP52, FMP54 Accessories ......115 Device-specific accessories ..... . 115 Communication-specific accessories .

  • Page 4: Important Document Information

    Levelflex FMP51, FMP52, FMP54 Important document information Symbols Safety symbols Symbol Meaning DANGER! This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in DANGER serious or fatal injury. WARNING! This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in WARNING serious or fatal injury.
  • Page 5 Levelflex FMP51, FMP52, FMP54 Symbols in graphics Symbol Meaning 1, 2, 3 ... Item numbers Series of steps … A, B, C, ... Views A-A, B-B, C-C, ... Sections Hazardous area Indicates a hazardous area. Safe area (non-hazardous area) Indicates the non-hazardous area.

  • Page 6: Function And System Design

    Levelflex FMP51, FMP52, FMP54 Function and system design Measuring principle Basic principles The Levelflex is a "downward-looking" measuring system that functions according to the ToF method (ToF = Time of Flight). The distance from the reference point to the product surface is measured.
  • Page 7 Levelflex FMP51, FMP52, FMP54 Dielectric constant The dielectric constant (DC) of the medium has a direct impact on the degree of reflection of the highfrequency pulses. In the case of large DC values, such as for water or ammonia, there is strong pulse reflection while, with low DC values, such as for hydrocarbons, weak pulse reflection is experienced.
  • Page 8 For dielectric constants (DC values) of many media commonly used in various industries refer • the Endress+Hauser DC manual (CP01076F) • the Endress+Hauser "DC Values App" (available for Android and iOS) For FMP55: Under certain conditions measurement is possible even with a changing DC. For details please contact your Endress+Hauser representative. Endress+Hauser...
  • Page 9 • Hardware and software developed according to SIL IEC 61508 • Genuine, direct interface measurement Procurement • Endress+Hauser being the world market leader in level measurement guarantees asset protection • Worldwide support and service Installation • Special tools are not required •...

  • Page 10: Measuring System

    Maximum probe length for indivisible rod probes: 4 m (13 ft) If required, rod and rope probes can be replaced. They are secured with Nord-Lock washers or a thread coating. For further information on service and spare parts please contact the Endress+Hauser service. Endress+Hauser...
  • Page 11 Levelflex FMP51, FMP52, FMP54 Levelflex FMP52 Type of probe Rod probe Rope probe A0011357 A0011358 Feature 060 - Probe: Option: Option: 16 mm (PFA>316L) 4 mm (PFA>316), max. 150 mm nozzle height, center rod 0.63 in (PFA>316L) 4 mm (PFA>316), max. 300 mm nozzle height, center rod 1/6"...

  • Page 12: Input

    Levelflex FMP51, FMP52, FMP54 Input Measured variable The measured variable is the distance between the reference point and the product surface. Subject to the empty distance entered "E" the level is calculated. Alternatively, the level can be converted into other variables (volume, mass) by means of linearization (32 points).
  • Page 13 Levelflex FMP51, FMP52, FMP54 Levelflex FMP52 Measuring range Media group DC (ε Typical liquids PFA-coated PFA-coated rod probes rope probes 1.4...1.6 condensed gases, e.g. N , CO — — 1.6...1.9 • liquefied gas, e.g. propane 4 m (13 ft) 9 to 14 m (30 to 46 ft) •...

  • Page 14: Blocking Distance

    Levelflex FMP51, FMP52, FMP54 Blocking distance The upper blocking distance (= UB) is the minimum distance from the reference point of the measurement (mounting flange) to the maximum level. 100% A0011279  3 Definition of blocking distance and safety distance...

  • Page 15: Output

    Levelflex FMP51, FMP52, FMP54 Output Output signal HART Signal coding FSK ±0.5 mA over currency signal Data transmission rate 1200 Baud Galvanic isolation PROFIBUS PA Signal coding Manchester Bus Powered (MBP) Data transmission rate 31,25 KBit/s, voltage mode Galvanic isolation...

  • Page 16: Signal On Alarm

    Levelflex FMP51, FMP52, FMP54 Switch output Function Open collector switching output Switching behavior Binary (conductive or non-conductive), switches when the programmable switch point is reached Failure mode non-conductive Electrical connection U = 10.4 to 35 V , I = 0 to 40 mA...

  • Page 17: Protocol-Specific Data

    Levelflex FMP51, FMP52, FMP54 Protocol-specific data HART Manufacturer ID 17 (0x11) Device type ID 0x34 HART specification Device description files (DTM, Information and files at: • www.endress.com • www.hartcomm.org HART load Min. 250 Ω HART device variables The measured values can be freely assigned to the device variables.
  • Page 18 Levelflex FMP51, FMP52, FMP54 PROFIBUS PA Manufacturer ID 17 (0x11) Ident number 0x1558 Profile version 3.02 GSD file Information and files at: • www.endress.com GSD file version • www.profibus.org Output values Analog Input: • Level linearized • Distance • Interface •...
  • Page 19 Levelflex FMP51, FMP52, FMP54 FOUNDATION Fieldbus Manufacturer ID 0x452B48 Device type 0x1022 Device Revision 0x01 DD Revision Information and files at: • www.endress.com CFF Revision • www.fieldbus.org Device Tester Version (ITK 6.01 Version) ITK Test Campaign Number IT080500 Link Master (LAS) capable Link Master / Basic Device yes;...
  • Page 20 Levelflex FMP51, FMP52, FMP54 Transducer Blocks Block Content Output values Setup Transducer Block Contains all parameters for a standard commissioning • Level or volume procedure (Channel 1) • Distance (Channel 2) Advanced Setup Contains all parameters for a more detailed...
  • Page 21 Levelflex FMP51, FMP52, FMP54 Function Blocks Block Content Number of Number of Execution Functionality permanent instantiable time blocks blocks Resource Block The Resource Block contains all the enhanced data that uniquely identify the field device. It is an electronic version of a nameplate of the device.

  • Page 22: Energieversorgung

    Levelflex FMP51, FMP52, FMP54 Energieversorgung Terminal assignment 2-wire: 4-20mA HART – – 4...20 mA – – 4...20 mA A0011294  4 Terminal assignment 2-wire; 4-20mA HART Without integrated overvoltage protection With integrated overvoltage protection Active barrier with power supply (e.g. RN221N): Observe terminal voltage HART communication resistor (≥250 Ω): Observe maximum load...
  • Page 23 Levelflex FMP51, FMP52, FMP54 2-wire: 4-20mA HART, switch output – 4...20 mA ³ – 4...20 mA ³ A0013759  5 Terminal assignment 2-wire; 4-20mA HART, switch output Without integrated overvoltage protection With integrated overvoltage protection Active barrier with power supply (e.g. RN221N): Observe terminal voltage HART communication resistor (≥250 Ω): Observe maximum load...
  • Page 24 Levelflex FMP51, FMP52, FMP54 2-wire: 4-20mA HART, 4-20mA – 4...20 mA – 4...20 mA – 4...20 mA – 4...20 mA A0013923  6 Terminal assignment 2-wire, 4-20 mA HART, 4...20mA Without integrated overvoltage protection With integrated overvoltage protection Connection current output 2 Connection current output 1 Supply voltage for current output 1 (e.g.
  • Page 25 Levelflex FMP51, FMP52, FMP54 4-wire: 4-20mA HART (10.4 to 48 V 4...20 mA ³ A0011340  7 Terminal assignment 4-wire; 4-20mA HART (10.4 to 48 VDC) Evaluation unit, e.g. PLC HART communication resistor (≥250 Ω): Observe maximum load Connection for Commubox FXA195 or FieldXpert SFX350/SFX370 (via VIATOR Bluetooth modem)
  • Page 26 Levelflex FMP51, FMP52, FMP54 4-wire: 4-20mA HART (90 to 253 V 4...20 mA ³ A0018965  8 Terminal assignment 4-wire; 4-20mA HART (90 to 253 VAC) Evaluation unit, e.g. PLC HART communication resistor (≥250 Ω): Observe maximum load Connection for Commubox FXA195 or FieldXpert SFX350/SFX370 (via VIATOR Bluetooth modem)
  • Page 27 Levelflex FMP51, FMP52, FMP54 PROFIBUS PA / FOUNDATION Fieldbus A0011341  9 Terminal assignment PROFIBUS PA / FOUNDATION Fieldbus Without integrated overvoltage protection With integrated overvoltage protection Cable screen: Observe cable specifications Switch output (open collector): Terminals 3 and 4...
  • Page 28 Levelflex FMP51, FMP52, FMP54 Connection examples for the switch output For HART devices, the switch output is available as an option. See product structure, feature 20: "Power Supply, Output", option B: "2-wire; 4-20mA HART, switch output" Devices with PROFIBUS PA and FOUNDATION Fieldbus always have a switch output.
  • Page 29 Levelflex FMP51, FMP52, FMP54 HART loop converter HMX50 The dynamic variables of the HART protocol can be converted into individual 4 to 20 mA sections using the HART loop converter HMX50. The variables are assigned to the current output and the measuring ranges of the individual parameters are defined in the HMX50.

  • Page 30: Device Plug Connectors

    Levelflex FMP51, FMP52, FMP54 Device plug connectors For the versions with fieldbus plug connector (M12 or 7/8"), the signal line can be connected without opening the housing. Pin assignment of the M12 plug connector Meaning Signal + not connected Signal -...

  • Page 31: Power Supply

    Levelflex FMP51, FMP52, FMP54 Power supply An external power supply is required. Various supply units can be ordered from Endress+Hauser: see "Accessories" section →  124 2-wire, 4-20mA HART, passive 2-wire; 4-20mA HART "Approval" Terminal voltage U at the device...
  • Page 32 Levelflex FMP51, FMP52, FMP54 2-wire; 4-20mA HART, 4-20mA "Approval" Terminal voltage U at the device Maximum load R, depending on the supply voltage U at the supply unit alle Channel 1: 13.5 to 30 V R [ ] W 13.5 24.5...

  • Page 33: Power Consumption

    Levelflex FMP51, FMP52, FMP54 4-wire, 4-20mA HART, active "Power supply; Output" Terminal voltage Maximum load R K: 4-wire 90-253VAC; 4-20mA HART 90 to 253 V (50 to 60 Hz), overvoltage 500 Ω category II L: 4-wire 10,4-48VDC; 4-20mA HART 10.4 to 48 V...

  • Page 34: Power Supply Failure

    Levelflex FMP51, FMP52, FMP54 FOUNDATION Fieldbus Device basic current 15 mA Error current FDE (Fault 0 mA Disconnection Electronic) FISCO 17.5 V 550 mA 5.5 W 5 nF 10 μH Power supply failure • Configuration is retained in the HistoROM (EEPROM).

  • Page 35: Overvoltage Protection

    < 1.5 pF Nominal arrest impulse voltage (8/20 μs) 10 kA External overvoltage protection HAW562 or HAW569 from Endress+Hauser are suited as external overvoltage protection. For detailed information please refer to the following documents: • HAW562: TI01012K • HAW569: TI01013K...

  • Page 36: Performance Characteristics

    Levelflex FMP51, FMP52, FMP54 Performance characteristics Reference operating • Temperature = +24 °C (+75 °F) ±5 °C (±9 °F) conditions • Pressure = 960 mbar abs. (14 psia) ±100 mbar (±1.45 psi) • Humidity = 60 % ±15 % • Reflection factor ≥ 0,8 (water surface for coax probe, metal plate for rod and rope probe with min.
  • Page 37 Levelflex FMP51, FMP52, FMP54 Differing from this, the following measuring error is present in the vicinity of the lower probe end: 80 (3.15) 60 (2.36) DC = 2 40 (1.57) DC = 80 20 (0.79) -20 (-0.79) -40 (-1.57) -60 (-2.36) -80 (-3.15)
  • Page 38 Levelflex FMP51, FMP52, FMP54 120 (4.72) 100 (3.94) DC = 2 80 (3.15) 60 (2.36) DC = 80 40 (1.57) 20 (0.79) -20 (-0.79) -40 (-1.57) -60 (-2.36) -80 (-3.15) -100 (-3.94) -120 (-4.72) A0021483  15 Measuring error at the end-of-probe for probes with metallic centering disk (product structure: feature 610 "Accessory mounted", option OA, OB or OC)

  • Page 39: Resolution

    Levelflex FMP51, FMP52, FMP54 In the area of the upper probe end, the measuring error is as follows (rod/rope only): 40 (1.57) DC = 2 30 (1.18) DC = 80 10 (0.39) 2 (0.08) 0 (0) - 2 (- 0.08) - 10 (-0.39)

  • Page 40: Influence Of Gas Layer

    Levelflex FMP51, FMP52, FMP54 Influence of gas layer High pressures reduce the propagation velocity of the measuring signals in the gas/vapor above the fluid. This effect depends on the kind of gas/vapor and of its temperature. This results in a systematic measuring error that gets bigger as the distance increases between the reference point of the measurement (flange) and the product surface.

  • Page 41: Gas Phase Compensation With Reference Signal (Option For Fmp54)

    Levelflex FMP51, FMP52, FMP54 Gas phase compensation Under high pressure the propagation speed of microwave signals is reduced in the steam (polar media) above the liquid to be measured. As a result, the Levelflex indicates the level too low with reference signal (option →...
  • Page 42 Levelflex FMP51, FMP52, FMP54 Limitations for coax/rod probes Maximum probe length LN • For rod probes: LN ≤ 4 000 mm (157 in) • For coax probes: LN ≤ 6 000 mm (236 in) Minimum probe length LN LN > L + 200 mm (L + 7.7")

  • Page 43: Mounting

    Levelflex FMP51, FMP52, FMP54 Mounting Mounting requirements Suitable mounting position A0012606  17 Mounting requirements for Levelflex Mounting distances • Distance (A) between wall and rod or rope probe: – for smooth metallic walls: > 50 mm (2 in) – for plastic walls: > 300 mm (12 in) to metallic parts outside the vessel –...
  • Page 44 Levelflex FMP51, FMP52, FMP54 Additional conditions • When mounting in the open, a weather protection cover (1) may be installed to protect the device against extreme weather conditions. • In metallic vessels: Preferably do not mount the probe in the center of the vessel (2), as this would lead to increased interference echoes.
  • Page 45 Levelflex FMP51, FMP52, FMP54 Applications with restricted mounting space Mounting with remote sensor The device version with a remote sensor is suited for applications with restricted mounting space. In this case the electronics housing is mounted at a separate position from which it is easier accessible.
  • Page 46 Levelflex FMP51, FMP52, FMP54 Divisible probes 14 mm 14 mm A0021647 If there is little mounting space (distance to the ceiling), it is advisable to use divisible rod probes ( 16 mm). • max. probe length 10 m (394 in) •...
  • Page 47 Levelflex FMP51, FMP52, FMP54 Notes on the mechanical load of the probe Tensile load limit of rope probes Sensor Feature 060 Probe Tensile load limit [kN] FMP51 LA, LB Rope 4mm (1/6") 316 MB, MD FMP52 OA, OB, OC, OD Rope 4mm (1/6") PFA>316...
  • Page 48 Levelflex FMP51, FMP52, FMP54 Bending torque [M] on rod probes, diameter 8mm (1/3”) 20.0 18.0 16.0 14.0 12.0 10.0 v=0.5m/s v=0.7m/s v=1.0m/s Probe length [ ] in meters A0014182-EN Bending strength of coax probes Sensor Feature 060 Process connection Probe...
  • Page 49 Levelflex FMP51, FMP52, FMP54 Notes on the process connection Probes are mounted to the process connection with threaded connections or flanges. If during this installation there is the danger that the probe end moves so much that it touches the tank floor or cone at times, the probe must, if necessary, be shortened and fixed down →...
  • Page 50 Levelflex FMP51, FMP52, FMP54 Nozzle mounting ø 150 (6) mm (in) £ A0015122 • Permissible nozzle diameter: ≤ 150 mm (6 in). For larger diameters the near range measuring capability may be reduced. For nozzles ≥ DN300: →  53.
  • Page 51 Levelflex FMP51, FMP52, FMP54 Center rod for FMP51 and FMP52 For rope probes it may be necessary to use a version with center rod in order to prevent the probe rod from coming into contact with the nozzle wall. Probes with center rod are available for FMP51 and FMP52.
  • Page 52 Levelflex FMP51, FMP52, FMP54 Rod extension/centering HMP40 for FMP54 For FMP54 with rope probes the rod extension/centering HMP 40 is available as an accessory →  117. It has to be used if otherwise the probe rope comes into contact with the lower edge of the nozzle.
  • Page 53 Levelflex FMP51, FMP52, FMP54 Installation in nozzles ≥ DN300 If installation in ≥ 300mm/12" nozzles is unavoidable, installation must be carried out in accordance with the following sketch. A0014199 Lower edge of the nozzle Approx. flush with the lower edge of the nozzle (± 50 mm/2") Plate Pipe ...
  • Page 54 Levelflex FMP51, FMP52, FMP54 Mounting cladded flanges For cladded flanges of FMP52, observe the following: • Use flange screws according to the number of flange holes. • Tighten the screws with the required torque (see table). • Retighten the screws after 24 hours or after the first temperature cycle.
  • Page 55 Levelflex FMP51, FMP52, FMP54 Securing the probe Securing rope probes A0012609 Sag of the rope: ≥ 1 cm per 1m of the probe length (0.12 inch per 1 ft of the probe length) Reliably grounded end of probe Reliably isolated end of probe...
  • Page 56 Levelflex FMP51, FMP52, FMP54 Securing rod probes • For WHG approvals: For probe lengths ≥ 3 m (10 ft) a support is required. • In general, rod probes must be supported if there is a horizontal flow (e.g. from an agitator) or in the case of strong vibrations.
  • Page 57 Levelflex FMP51, FMP52, FMP54 Securing coax probes For WHG approvals: For probe lengths ≥ 3 m (10 ft) a support is required. A0012608 Coax probes can be supported at any point of the outer tube. Endress+Hauser...
  • Page 58 Levelflex FMP51, FMP52, FMP54 Special mounting conditions Bypasses and stilling wells In bypass and stilling well applications it is recommended to use a centering disks or stars. øD A0012615  19 Dimensions: mm (in) Mounting in a stilling well Mounting in a bypass...
  • Page 59 With heat insulated tanks the bypass should also be insulated in order to prevent condensate formation. For information on bypass solutions from Endress+Hauser please contact your Endress+Hauser sales representative. Endress+Hauser...
  • Page 60 Levelflex FMP51, FMP52, FMP54 Installation in horizontal and upright cylindrical tanks A0014141 • Any distance from wall, as long as occasional contact is prevented. • When installing in tanks with a lot of internals or internals situated close to the probe: use a coax probe.
  • Page 61 Levelflex FMP51, FMP52, FMP54 Underground tanks A0014142 Use a coax probe for nozzles with large diameters in order to avoid reflections at the nozzle wall. Endress+Hauser...
  • Page 62 Levelflex FMP51, FMP52, FMP54 Installation at an angle A0014145 • For mechanical reasons, the probe should be installed as vertically as possible. • With inclined installations the probe length has to be adjusted in dependence to the installation angle. – Up to LN = 1 m (3.3 ft): α = 30°...
  • Page 63 Levelflex FMP51, FMP52, FMP54 Non-metallic vessels A0012527 Non-metallic vessel Metal sheet or metal flange To measure, Levelflex with a rod probe needs a metallic surface at the process connection. Therefore: • Select an instrument version with metal flange (minimum size DN50/2").
  • Page 64 Levelflex FMP51, FMP52, FMP54 Plastic or glass tanks: Mounting the probe externally at the wall A0014150 Plastic or glass tank Metall sheet with threaded sleeve No free space between tank wall and probe! Requirements • The dielectric constant of the medium must be at least DC > 7.
  • Page 65 Levelflex FMP51, FMP52, FMP54 Vessels with heat insulation If process temperatures are high, the device must be included in normal tank insulation to prevent the electronics heating up as a result of heat radiation or convection. The insulation may not exceed beyond the points labeled "MAX" in the drawings.
  • Page 66 Levelflex FMP51, FMP52, FMP54 XT 280 °C (536 °F)* HT 450 °C (842 °F) A0014658  23 Process connection with flange - FMP54, sensor version XT and HT Tank insulation Compact device Sensor remote (feature 600) The XT version is not recommended for saturated steam above 200 °C (392 °F). Use the HT version instead.
  • Page 67 FMP51 and FMP54 are a perfect replacement for a conventional displacer system in an existing displacer chamber. Endress+Hauser offers flanges that suit Fischer and Masoneilan displacer chamber for this purpose (special product for FMP51; feature 100, options LNJ, LPJ, LQJ for FMP54).

  • Page 68: Operating Conditions: Environment

    Levelflex FMP51, FMP52, FMP54 Operating conditions: Environment Ambient temperature range Measuring device –40 to +80 °C (–40 to +176 °F) Local display –20 to +70 °C (–4 to +158 °F), the readability of the display may be impaired at temperatures outside the temperature range.
  • Page 69 Levelflex FMP51, FMP52, FMP54 With a temperature (T ) at the process connection the admissible ambient temperature (T ) is reduced according to the following diagram (temperature derating): Temperature derating for FMP51 with threaded connection G¾ or NPT¾ [°C] ([°F]) T a...
  • Page 70 Levelflex FMP51, FMP52, FMP54 Temperature derating for FMP51 with threaded connection G1½ or NPT1½ [°C] ([°F]) T a +80 (+176) GT20: +57 (+135) GT18: +49 (+120) 4 20 mA HART – GT19: +20 (+68) -40 (-40) [°C] +200 ([°F]) (-40)
  • Page 71 Levelflex FMP51, FMP52, FMP54 Temperature derating for FMP51 with flange [°C] ([°F]) T a +80 (+176) GT20: +59 (+138) GT18: +53 (+127) 4 20 mA HART – GT19: +33 (+91) -40 (-40) [°C] +200 (-40) ([°F]) (+180) (+392) [°C] ([°F]) T a...
  • Page 72 Levelflex FMP51, FMP52, FMP54 Temperature derating for FMP52 [°C] ([°F]) T a +80 (+176) GT20: +60 (+140) GT18: +53 (+127) GT19: +38 (+100) 4 20 mA HART – GT19: -36 (-33) GT18: -37 (-35) GT20: -38 (-36) -40 (-40) [°C]...
  • Page 73 Levelflex FMP51, FMP52, FMP54 Temperature derating for FMP54 - version XT up to +280 °C (+536 °F ) [°C] ([°F]) T a +80 (+176) GT20: +62 (+144) GT18: +56 (+133) GT19: +42 (+108) 4 20 mA HART – GT19: -5 (+23)
  • Page 74 Levelflex FMP51, FMP52, FMP54 Temperature derating for FMP54 - version HT up to +450 °C (+842 °F ) [°C] ([°F]) T a +80 (+176) GT20: +56 (+133) GT18: +54 (+129) GT19: +42 (+108) 4 20 mA HART – GT19: -22 (-8)

  • Page 75: Storage Temperature

    Levelflex FMP51, FMP52, FMP54 Storage temperature –40 to +80 °C (–40 to +176 °F) Climate class DIN EN 60068-2-38 (test Z/AD) Altitude according to Up to 2 000 m (6 600 ft) above MSL. IEC61010-1 Ed.3 Degree of protection • With closed housing tested according to: –...

  • Page 76: Process

    Levelflex FMP51, FMP52, FMP54 Process Process temperature range The maximum permitted temperature at the process connection is determined by the O-ring version ordered: Device O-ring material Process temperature Approval FMP51 FKM (Viton GLT –30 to +150 °C (–22 to +302 °F) 37559) –40 to +150 °C (–40 to +302 °F)

  • Page 77: Dielectric Constant (Dc)

    Levelflex FMP51, FMP52, FMP54 FMP54 - process pressure depending on the process temperature [bar] ([psi]) p 420 (6090) 400 (5800) 380 (5510) 350 (5075) 320 (4640) 300 (4350) [°C] -196 -100 +100 ([°F]) (-321) (-148) (+32) (+212) (+392) (+572) (+752)

  • Page 78: Mechanical Construction

    Levelflex FMP51, FMP52, FMP54 Mechanical construction Dimensions Dimensions of the electronics housing 98 (3.86)* 78 (3.07) 90 (3.54) A0011666  24 Housing GT18 (316L); Dimensions in mm (in) *for devices with integrated overvoltage protection. 99.5 (3.92)* 90 (3.54) 78 (3.07) A0011346 ...
  • Page 79 Levelflex FMP51, FMP52, FMP54 Dimensions of the mounting bracket ø42...60 (1.65...2.36) 122 (4.8) 140 (5.5) 175 (6.9) 158 (6.2) A0014793  27 Mounting bracket for the electronics housing: dimensions: mm (in) Wall mounting Pipe mounting For the "Sensor remote" device version (see feature 060 of the product structure), the mounting bracket is part of the delivery.
  • Page 80 Levelflex FMP51, FMP52, FMP54 FMP51: Dimensions of process connection (G¾,NPT¾) and probe ø59.35 (2.34) SW36 AF36 G¾ NPT¾ ø10 (0.4) ø4 (0.16) ø4 (0.16) ø8 (0.31) ø22 (0.87) 2 (0.08) ø29 (1.14) 8 (0.31) ø75 (2.95) ø22 0 ( .87) A0012645 ...
  • Page 81 Levelflex FMP51, FMP52, FMP54 FMP51: Dimensions of process connection (G1½,NPT1½,flange) and probe ø59.35 ø59.35 ø59.35 (2.34) (2.34) (2.34) SW55 SW55 AF55 AF55 G1½ NPT1½ SW10 AF10 SW14 ø10 (0.4) SW10 AF14 AF10 SW10 ø16 (0.63) ø10 (0.4) AF10 ø4 0 ( .16) ø4 0 ( .16)
  • Page 82 Levelflex FMP51, FMP52, FMP54 PEEK 7 mm (0.28 in) 95 mm (3.74 in) 10 mm (0.39 in) 37 mm (1.46 in) 316L 4 mm (0.16 in) 45 mm (1.77 in) 75 mm (2.95 in) FMP52: Dimensions of process connection and probe ø90.89...
  • Page 83 Levelflex FMP51, FMP52, FMP54 FMP54: Dimensions of process connection and probe SW60 SW60 AF60 AF60 ø90 ø90 ø90 ø90 (3.54) (3.54) (3.54) (3.54) SW14 SW14 SW14 SW14 AF14 AF14 AF14 AF14 M40x1 M40x1 M40x1 M40x1 ø16 (0.63) SW14 SW14 AF14 AF14 ø16 (0.63)
  • Page 84 Levelflex FMP51, FMP52, FMP54 PEEK 7 mm (0.28 in) 95 mm (3.74 in) 10 mm (3.94 in) 37 mm (1.46 in) 316L 4 mm (0.16 in) 45 mm (1.77 in) 75 mm (2.95 in) Endress+Hauser...

  • Page 85: Tolerance Of Probe Length

    Levelflex FMP51, FMP52, FMP54 Tolerance of probe length Rod and coax probes Over [m (ft)] — 1 (3,3) 3 (9,8) 6 (20) Up to [m (ft)] 1 (3,3) 3 (9,8) 6 (20) — Admissible tolerance [mm -5 (-0,2) -10 (-0,39)

  • Page 86: Weight

    Levelflex FMP51, FMP52, FMP54 Weight Housing Part Weight Housing GT18 - stainless steel approx. 4.5 kg Housing GT19 - plastic approx. 1.2 kg Housing GT20 - aluminium approx. 1.9 kg FMP51 with threaded connection G¾ or NPT¾ Part Weight Part...

  • Page 87: Materials: Gt18 Housing

    Levelflex FMP51, FMP52, FMP54 Materials: GT18 housing A0013788 No. Part Material Housing CF-3M (316L, 1.4404) 2.1 Cover of the electronics compartment • Cover: CF-3M (316L, 1.4404) • Window: glass • Cover seal: EPDM • Seal of the window: NBR • Thread-coating: Graphite-based lubricant varnish 2.2 Cover of the terminal compartment...

  • Page 88: Materials: Gt19 Housing

    Levelflex FMP51, FMP52, FMP54 Materials: GT19 housing A0013788 No. Part Material Housing 2.1 Cover of the electronics compartment • Cover, depending on the device version: – PA (see-through cover) – PBT (non-transparent cover) • Cover seal: EPDM • Thread-coating: Graphite-based lubricant varnish 2.2 Cover of the terminal compartment...

  • Page 89: Materials: Gt20 Housing

    Levelflex FMP51, FMP52, FMP54 Materials: GT20 housing A0013788 Nr. Part Material Housing, RAL 5012 (blue) • Housing: AlSi10Mg(<0,1% Cu) • Coating: Polyester 2.1 Cover of the electronics compartment; RAL 7035 • Cover: AlSi10Mg(<0,1% Cu) (gray) • Window: Glass • Cover seal: EPDM •...
  • Page 90 Levelflex FMP51, FMP52, FMP54 Nr. Part Material Ground terminal • Screw: A2 • Spring washer: A2 • Clamp: 304 (1.4301) • Holder: 304 (1.4301) Nameplate Sticker For the version with M12 plug the sealing material is Viton. For the version with 7/8" plug, the sealing material is NBR.

  • Page 91: Materials: Process Connection

    Levelflex FMP51, FMP52, FMP54 Materials: Process Endress+Hauser supplies DIN/EN flanges and threaded process connections made of stainless steel according to AISI 316L (DIN/EN material number 1.4404 or 1.4435). With regard to their connection temperature stability properties, the materials 1.4404 and 1.4435 are grouped under 13E0 in EN 1092-1 Tab.

  • Page 92: Materials: Probe

    Levelflex FMP51, FMP52, FMP54 Materials: Probe Levelflex FMP51 Rope probe Rod probe Coax probe  4 mm (1/6")  12.7 Thread Thread No. Material  4 mm  8 mm Thread with mm (1/2") G1-1/2 G1-1/2 (1/6") (1/3") G3/4 centering...
  • Page 93 Levelflex FMP51, FMP52, FMP54 Levelflex FMP52 Rod probe Rope probe No. Material  16 mm (2/3") coated  4 mm (1/6") coated 316L (1.4404) Coating 2 mm (0.08 in): PFA (Daikin PFA AP230) Rope: 316 (1.4401) Coating 0.75mm (0.03 in): PFA (Daikin PFA AP230) Core: 316L (1.4435)

  • Page 94: Materials: Mounting Bracket

    Levelflex FMP51, FMP52, FMP54 Materials: Mounting bracket A0015143 Mounting bracket for version "Sensor remote" Position Part Material Bracket 316L (1.4404) Bracket 316Ti (1.4571) Screw/nuts A4-70 Distance sleeves 316Ti (1.4571) or 316L (1.4404) Half-shells 316L (1.4404) Endress+Hauser...

  • Page 95: Materials: Adapter And Cable For Remote Display

    Levelflex FMP51, FMP52, FMP54 Materials: Adapter and cable for remote display A0021722 Adapter and cable for version "Sensor remote" Position Part Material Cable FRNC Sensor adapter 304 (1.4301) Clamp 316L (1.4404) Screw A4-70 Loop 316 (1.4401) Crimp sleeve Aluminum Nameplate 304 (1.4301)

  • Page 96: Materials: Weather Protection Cover

    Levelflex FMP51, FMP52, FMP54 Materials: Weather protection cover A0015473 Part: Material Protection cover: 316L (1.4404) Molded rubber part (4x): EPDM Clamping screw: 316L (1.4404) + carbon fibre Bracket: 316L (1.4404) • Cheese head screw: A4-70 • Nut: A4 • Spring washer: A4 Ground terminal •...

  • Page 97: Operability

    Levelflex FMP51, FMP52, FMP54 Operability Operating concept Operator-oriented menu structure for user-specific tasks • Commissioning • Operation • Diagnostics • Expert level Operatring languages • English (contained in every device) • One additional language as ordered (feature 500 of the product structure) Quick and safe commissioning •...

  • Page 98: Operation With Remote Display And Operating Module

    Levelflex FMP51, FMP52, FMP54 Operation with remote display and operating module FHX50 A0013137  33 FHX50 operating options Housing of the remote display and operating module FHX50 Display and operating module SD02, push buttons; cover must be removed Display and operating module SD03, optical keys; can be operated through the glass of the cover...
  • Page 99 Levelflex FMP51, FMP52, FMP54 Via PROFIBUS PA protocol PROFIBUS DP ENDRESS + HAUSER PROFIBUS PA A0015775 Segment coupler Computer with Profiboard/Proficard and operating tool (e.g. FieldCare) PLC (Progrommable Logic Controller) Transmitter Additional functions (valves etc.) Endress+Hauser...
  • Page 100 Levelflex FMP51, FMP52, FMP54 Via FOUNDATION Fieldbus FF-HSE FF-H1 ENDRESS + HAUSER – FF-H1 A0017188  35 FOUNDATION Fieldbus system architecture with associated components FFblue Bluetooth modem Field Xpert SFX350/SFX370 FieldCare NI-FF interface card Industrial network FF-HSE High Speed Ethernet...
  • Page 101 Levelflex FMP51, FMP52, FMP54 Via service interface (CDI) A0014019 Service interface (CDI) of the measuring device (= Endress+Hauser Common Data Interface) Commubox FXA291 Computer with "FieldCare" operating tool Endress+Hauser...

  • Page 102: Integration In Tank Gauging System

    Levelflex FMP51, FMP52, FMP54 Integration in tank gauging The Endress+Hauser Tank Side Monitor NRF590 provides integrated communications for sites with multiple tanks, each with one or more sensors on the tank, such as radar, spot or average system temperature, capacitive probe for water detection and/or pressure sensors. Multiple protocols out of the Tank Side Monitor guarantee connectivity to nearly any of the existing industry standard tank gauging protocols.

  • Page 103: System Integration Via Fieldgate

    The number of instruments which can be connected in mutidrop mode can be calculated by the "FieldNetCalc" program. A description of this program can be found in Technical Information TI 400F (Multidrop Conncector FXN520). The program is available form your Endress+Hauser sales organisation or in the internet at: www.de.endress.com/Download...

  • Page 104: Certificates And Approvals

    The measuring system meets the legal requirements of the applicable EC guidelines. These are listed in the corresponding EC Declaration of Conformity together with the standards applied. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. C-Tick symbol The measuring system meets the EMC requirements of the "Australian Communications and Media...

  • Page 105: Ad2000

    Levelflex FMP51, FMP52, FMP54 AD2000 • For FMP51/FMP54: The wetted material 316L (1.4435/1.4404) corresponds to AD2000 - W2/W10. • For FMP52/FMP55: The pressure retaining material 316L (1.4435/1.4404) corresponds to AD2000 - W2/W10. • Declaration of conformity: see product structure, feature 580, option JF.
  • Page 106 Levelflex FMP51, FMP52, FMP54 Feature 010 of the product structure Approval 1-1/2" 150lbs RF, 316/316L flange ANSI B16.5 1-1/2" 150lbs, PTFE>316/316L flange ANSI B16.5 1-1/2" 150lbs, AlloyC>316/316L flange ANSI B16.5 2" 150lbs RF, 316/316L flange ANSI B16.5 2" 150lbs, PTFE>316/316L flange ANSI B16.5 2"...

  • Page 107: Track Record

    Levelflex FMP51, FMP52, FMP54 • Process connections without CRN approval are not included in this table. • Refer to the product structure to see which process connections are available for a specific device type. • CRN approved devices are marked with the registration number 0F14480.5 on the nameplate.

  • Page 108: Test, Certificate

    Levelflex FMP51, FMP52, FMP54 Test, Certificate Feature 580 Designation Available for "Test, Certificate" 3.1 Material certificate, wetted metallic parts, EN10204-3.1 inspection • FMP51 certificate • FMP54 Conformity to NACE MR0175, wetted metallic parts • FMP51 • FMP54 3.1 Material certificate, pressurized parts, EN10204-3.1 inspection...

  • Page 109: Other Standards And Guidelines

    Levelflex FMP51, FMP52, FMP54 Other standards and • EN 60529 Degrees of protection by housing (IP code) guidelines • EN 61010-1 Protection Measures for Electrical Equipment for Measurement, Control, Regulation and Laboratory Procedures. • IEC/EN 61326 "Emission in accordance with Class A requirements". Electromagnetic compatibility (EMC requirements) •...

  • Page 110: Ordering Information

    Ordering information Ordering information Detailed ordering information is available from the following sources: • In the Product Configurator on the Endress+Hauser web site: www.endress.com → Choose your country → Products → Select measuring technology, software or components → Select product (picklists: measurement method, product family etc.) →...
  • Page 111 Levelflex FMP51, FMP52, FMP54 3-point linearity protocol The following notes must be taken into account if option F3 ("3 point linearity protocol") has been selected in feature 550 ("Calibration"). Depending on the probe the 3 points of the linearity protocol are defined as follows:...

  • Page 112: 5-Point Linearity Protocol

    Levelflex FMP51, FMP52, FMP54 5-point linearity protocol The following notes must be taken into account if option F4 ("5 point linearity protocol") has been selected in feature 550 ("Calibration"). The five points of the linearity protocol are evenly distributetd across the measuring range (0% to 100%).
  • Page 113 Levelflex FMP51, FMP52, FMP54 Type of probe Minimum distance from Maximum value for end of probe to 0% level "empty calibration" Rod (not divisible) C ≥ 100 mm (4 in) E ≤ 3.9 m (12.8 ft) • Coax C ≥ 100 mm (4 in) E ≤...

  • Page 114: Customized Parametrization

    Levelflex FMP51, FMP52, FMP54 Customized parametrization If the option IJ "Customized parametrization HART", IK "Customized parametrization PA" or IL "Customized parametrization FF" has been selected in feature 570 "Service", customer specific presettings can be selected for the following parameters: Parameter...

  • Page 115: Accessories

    Levelflex FMP51, FMP52, FMP54 Accessories Device-specific accessories Weather protection cover Accessory Description Weather protection cover A0015466 298.5 (11.8) 273.7 (10.8) 255.1 (10) 164 (6.46) A0015472  38 Weather protection cover; Dimensions: mm (in) 37,8 mm (1,5 in) 54 mm (2,1 in) ...
  • Page 116 Levelflex FMP51, FMP52, FMP54 Mounting bracket for the electronics housing Accessory Description Mounting bracket for the electronics housing ø42...60 (1.65...2.36) 122 (4.8) 140 (5.5) 175 (6.9) 158 (6.2) A0014793  39 Mounting bracket for the electronics housing; Dimensions: mm (in)
  • Page 117 Levelflex FMP51, FMP52, FMP54 Extension rod / centering HMP40 Accessory Description Extension rod / centering HMP40 • can be used for: FMP54 • Admissible temperature at lower nozzle edge: – without center washer: no limitation – with center washer: -40 to 150 °C (-40 to 302 °F)
  • Page 118 Levelflex FMP51, FMP52, FMP54 Mounting kit, isolated Accessory Description Mounting kit, isolated can be used for • FMP50 • FMP51 • FMP54 • FMP56 • FMP57 A0013586  40 Scope of supply of the mounting kit: Insulating sleeve Eye-bolt For reliably insulated fixing of the probe.
  • Page 119 Levelflex FMP51, FMP52, FMP54 Centering star Accessory Description Centering star PEEK  48 10 (0.39) to 95 mm (1.89 to 3.74 inch) can be used for • FMP51 • FMP54 ø48 (1.89) ø75 (2.95) ø95 (3.74) A0014576 The centering star is suitable for probes with a rod diameter of 16 mm (0.6 in) and can be used in pipes from DN40 (1½") up to DN100 (4").
  • Page 120 Levelflex FMP51, FMP52, FMP54 Accessory Description Centering star PFA •  16.4 mm (0.65 in) •  37 mm (1.46 in) can be used for • FMP51 • FMP52 • FMP54 A0014577 For 8 mm (0.3 in) probes For 12 mm (0.47 in) and 16 mm (0.63 in) probes The centering star is suitable for probes with a rod diameter of 8 mm (0.3 in),...
  • Page 121 Levelflex FMP51, FMP52, FMP54 Remote display FHX50 Accessory Description Remote display FHX50 A0019128 • Material: – Plastics PBT – 316L • Ingress protection: IP68 / NEMA 6P and IP66 / NEMA 4x • Suitable for the display modules: – SD02 (push buttons) –...
  • Page 122 Levelflex FMP51, FMP52, FMP54 Overvoltage protection Accessory Description Overvoltage protection for 2-wire-devices OVP10 (1 channel) OVP20 (2 channel) A0021734 Technical data • Resistance per channel: 2 * 0.5 Ω • Threshold DC voltage: 400 to 700 V • Threshold impulse voltage: < 800 V •...

  • Page 123: Communication-Specific Accessories

    For details refer to Technical Information TI00404F Accessory Description Commubox FXA291 Connects Endress+Hauser field devices with CDI interface (= Endress+Hauser Common Data Interface) to the USB interface of a computer. Order code: 51516983  For details refer to Technical Information TI00405C...

  • Page 124: Service-Specific Accessories

    Service-specific accessories Accessory Description FieldCare Endress+Hauser' s FDT-based Plant Asset Management tool. Helps to configure and maintain all field devices of your plant. By supplying status information it also supports the diagnosis of the devices.  For details refer to Operating Instructions BA00027S and BA00059S.

  • Page 125: Documentation

    For an overview of the scope of the associated Technical Documentation, refer to the following: • The W@M Device Viewer : Enter the serial number from the nameplate (www.endress.com/deviceviewer) • The Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2-D matrix code (QR code) on the nameplate. Standard documentation...

  • Page 126: Safety Documentation

    Levelflex FMP51, FMP52, FMP54 Safety documentation Safety Instructions (XA) Depending on the approval, the following Safety Instructions (XA) are supplied with the device. They are an integral part of the Operating Instructions. Feature 010 Approval Available for Feature 020: "Power Supply; Output"...
  • Page 127 Levelflex FMP51, FMP52, FMP54 Feature 010 Approval Available for Feature 020: "Power Supply; Output" IEC Ex ia IIC T6 Ga/Gb • FMP51 • FMP52 XA00496F XA01125F XA01126F XA00516F - • FMP54 IEC Ex d[ia] IIC T6 Ga/Gb • FMP51 XA00499F XA00499F XA00499F XA00519F XA01133F •...
  • Page 128 Levelflex FMP51, FMP52, FMP54 Feature 010 Approval Available for Feature 020: "Power Supply; Output" NEPSI Ex nA II T6 Gc • FMP51 XA00635F XA00635F XA00635F XA00641F XA00635F • FMP52 • FMP54 NEPSI Ex ic IIC T6 Gc • FMP51 XA00635F XA00635F XA00635F XA00641F XA00635F •...
  • Page 129 Levelflex FMP51, FMP52, FMP54 Ex-marking in case of connected FHX50 remote display If the device is prepared for the remote display FHX50 (product structure: feature 030: Display, Operation", option L or M), the Ex marking of some certificates changes according to the following table Feature 010 ("Approval") Feature 030 ("Display, Operation") Ex-marking...

  • Page 130: Registered Trademarks

    Levelflex FMP51, FMP52, FMP54 Registered trademarks HART ® Registered trademark of the HART Communication Foundation, Austin, USA PROFIBUS ® Registered trademark of the PROFIBUS User Organization, Karlsruhe, Germany FOUNDATION Fieldbus Registered trademark of the Fieldbus Foundation, Austin, Texas, USA KALREZ ®...

  • Page 131: Patents

    Levelflex FMP51, FMP52, FMP54 Patents This product may be protected by at least one of the following patents. Further patents are pending. US Patents EP Patents 5.827.985 5.884.231 5.973.637 6.087.978 955 527 6.140.940 6.481.276 6.512.358 1 301 914 6.559.657 1 020 735 6.640.628...
