Levelflex FMP51, FMP52, FMP54
Factory setting
Diameter
Navigation
Condition
Description
Input range
Factory setting
Additional information
Intermediate height
Navigation
Condition
Description
Input range
Factory setting
Additional information
Table mode
Endress+Hauser
100
Setup ® Advanced setup ® Linearization ® Diameter
Only visible if one of the following linearization types has been selected:
• Horizontal cylinder
• Sphere
Definition of the tank diameter
0 ... 9999.999 m (32808 ft)
2 m (6.6 ft)
The value must be specified in the selected distance unit (® ä 116).
Setup ® Advanced setup ® Linearization ® Intermediate height
Only visible if one of the following linearization types has been selected:
• Pyramid bottom
• Conical bottom
• Angled bottom
Definition of the intermediate height H
0 to 200 m (0 to 656 ft)
0 m (0 ft)
The value must be specified in the selected distance unit (® ä 116).
Description of device parameters (operating menu)
0%
H
A0013264
139
