Integrity Test HDF Online
Simultaneous pressure build-up of DF
filter and HDF filter
Repeats until error message
Actions after error
LLC Test
Code
1502x
1.
Prerequisites for Test:
Upline tank must be filled,
PSAUS, PSABF and BPV cover must be closed.
Timeout 2 min
Test code = 15 to LLS
2.
1510x
3.
Pressure Reduction for VBE Test with FPA:
Pressure reduction with FPA until PDA < -300
mmHg
Valve Status:
VDEBK1/2, VEBK1/2 -------------------- closed
VDABK1/2, VABK1/2------------------- opened
VBE, VDFF, VDE, VSB-------------------- closed
VBP, VDA, VSAE, VSAA----------------- opened
Timeout 1 min
1515x
4.
VBE Pressure Test
Valve Status:
VDEBK1/2, VEBK1/2 -------------------- closed
VDABK1/2, VABK1/2-------------------- closed
VBE, VDFF, VDE, VSB-------------------- closed
VBP, VDA, VSAE, VSAA----------------- opened
Test timeout 1 min or wait for switch-off VGD
from LLS
1520x
5.
Pressure Reduction for VSAE Test with UFP:
Pressure reduction with UFP until PDA < -300
mmHg
Valve Status:
VDEBK1/2, VEBK1/2 ------------------- opened
VDABK1/2, VABK1/2-------------------- closed
VBE, VDFF, VDE, VSB, VBP, VSAE--------- closed
VDA, VSAA---------------------------- opened
Timeout 1 min
1525x
6.
VSAE Pressure Test and OSP Test
FPE = 1000 ml/min
Valve Status:
VDEBK1/2, VEBK1/2 ------------------- opened
VDABK1/2, VABK1/2-------------------- closed
VBE, VDFF, VDE, VSB, VBP, VSAE--------- closed
VDA, VSAA---------------------------- opened
Test timeout 1 min or wait for switch-off VGD
from LLS
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 3_1-2010.doc/pdf <100329> yymmdd
3 . R e p a i r I n s t r u c t i o n s
Detection of safety relevant ruptures, pressure test of the substitution system in the
Objective
machine, pressure test of VBE/VSAE/VSAA.
Air can not pass the semipermeable filter membrane at negative pressure of > -500
mmHg. To detect ruptures: One side of the filter is filled with air; On the other side a
negative pressure < -270 mmHg is built up. If the pressure drop is < 20 mmHg in 3 min,
safety relevant ruptures are not present. The final opening of VBP must be detected by
LLS via PDA. Thus it is guaranteed that the filters were filled with air and VBE was
opened.
15
Test code
1
1151: HDF online filter test failed!
ID error message
Rinse, repeat all tests
LLC Test Steps
LLS Test Steps
Test code = 15 back to LLC
Start condition for the test (5 s):
4.
Correct valve position
5.
UFP stopped (UF rate < 500 ml/h)
6.
-450 mmHg < PDA < -150 mmHg
Test 10 s,
max. deviation ∆PDA < 50 mmHg,
PDA < -100 mmHg,
Acknowledge with switch-off of VGD
Start condition for the test (5 s):
1.
Correct valve position
2.
UFP stopped (UF rate < 500 ml/h)
3.
PDA < -150 mmHg
Test 10 s,
max. deviation ∆PDA < 50 mmHg,
PDA < -100 mmHg,
Test delivery rate OSP at 200 ±15 ml/min
Acknowledge with switch-off of VGD
1 / 2 0 1 0
3 - 29
LLS Test
Code
15001 –
15010
15011
15012 –
15018
15021 –
15030
15031,
15032
15033
15034 –
15039
