Dialog
SW 9.xx
B
B
D
C G
BA-TE-DE08W M.KAY
Dialog+ SW9xx_SM_Chapter 4-3-1_1_2010.doc/pdf <110301> yymmdd
4 . T S M S e r v i c e P r o g r a m
D
H E/F
Draw-Up of
Disinfectant
6.
Assemble servomotor B.
The position tag C of the servomotor B is
seated in the light barrier D. The bow G
(not visible) is seated in the groove F of
the eccentric axle.
H
7.
Plug in connector to disinfection valve
board matching with the motor.
8.
Check function of the disinfection valve
C
(position tag C in light barrier D).
I
1 / 2 0 1 0
B Servomotor
C Position tag
D Light barrier
E Bevel on eccentric axle
F groove
G Bow (only partly visible, is
seated in the eccentric
groove)
H Control disc
I
Rinsing bridge
B. Braun Avitum AG
4 - 172
