F i e l d S e r v i c e U t i l i t i e s V 2 . 0 0 - S e t M S T
01. Set System Version Number
02. Set Working Time Counter (WTC)
03. Kill Masterboot Record
04. Write Languages
05. Write Calibration Data
06. Write System Configuration
07. Undo Last Written
08. USB Stick Self Test
09. Select Menu of Card Reader Commands
10. Read System Configuration
11. Read Calibration Data
12. Read All Trends
13. Read Screenshots
14. Get Error (ErrorDisk)
BP-: move cursor up BP+: move cursor down AQ: exit – see Important Note EQ: execute
Important Note:
To prevent the corruption of USB stick, before removing it,
please press AQ then follow the instructions on the screen!
..........
..........
..........
..........
End of Error Disk...
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 3_1-2010.doc/pdf <100329> yymmdd
3 . R e p a i r I n s t r u c t i o n s
CRC = XXXX - OK
(Dialog+ Hard Disk)
(USB Stick → Dialog+ Hard Disk)
(USB Stick → Dialog+ Hard Disk)
(USB Stick → Dialog+ Hard Disk)
(USB Stick → Dialog+ Hard Disk)
(Dialog+ Hard Disk → USB Stick)
(Dialog+ Hard Disk → USB Stick)
(Dialog+ Hard Disk → USB Stick)
(Dialog+ Hard Disk → USB Stick)
(Dialog+ Hard Disk → USB Stick)
1 / 2 0 1 0
1. Press the BP
hardware key and move the cursor
down to select the utility.
2. Press the EQ
hardware key to execute the
utility.
An input screen opens and all the log files are read
from the Dialog+ hard disk drive (CFC) to the USB stick.
The Get Error (ErrorDisk) menu automatically returns (a
few seconds) to the main menu End of Error Disk... is
displayed.
3 - 92
B. Braun Avitum AG
