SW9.xx
3.8.3
Execution Protocol
3.8.2.1
Install Software
3.8.2.2
Check System Configuration, Production Report and Set if Necessary
3.8.2.3
Self Test
3.8.2.4
Conductivity Test Run, Temperature
Comparison Measurement:
3.8.2.5
Test Run UF Comparison Measurement:
3.8.2.6
Test Run
3.8.2.7
Electrical Safety Check:
According to:
IEC 62353/EN 60601-1/IEC 601-1
3.8.2.8
Perform Disinfection after Repair
4.
Tests and Calibrations According to Service Manual
All text in { } brackets are general notes or execution information!
{4.9.1.1
Buttons, Lamps and Sounds}
{4.9.1.3
Touch Screen Calibration}
{4.9.1.8
DBI Test or DSI Test or DCI Test}
{4.9.2.1
Test 1.1 Staff Call, Alarms, Power Off}
{4.9.2.5
1.5 Tubing Clamps}
{4.9.2.7
Test 1.7 Air Sensor SAD, Red Sensor}
{4.9.2.8
1.8 Coupling Detectors}
{4.9.2.13 1.13 Balance Chamber Valves}
{4.9.2.14 1.14 Bypass and Disinfection Valves}
{4.9.2.19 1.19 Leak Test}
{4.9.2.23 Test 1.23 BIC Cartridge Valves and Coupling Detectors}
{4.9.2.25 1.25 HDF Online Valves and Detectors}
{4.9.2.26 1.26 Option Battery
{4.9.4.1
Calibration Pressure Sensors Blood Side PA, PV, PBE and PBS}
{4.9.4.3
Calibration Pressure Sensors of Water Side PE and PDA}
{4.9.4.4
Calibration Degassing TSE/TSHE}
{4.9.4.5
Calibration Dialysis Temperature Sensors TSBIC and TSD/TSD_S/TSDE}
{4.9.4.6
Calibration Conductivity Sensors BICLF and ENDLF/ENDLF_S}
{4.9.4.7
Calibration Blood Leak Detector Type 3}
{4.9.4.8
Calibration of Flow Rate UFP, BICP and KP}
{4.9.4.9
Calibration Safety Air Detector SAD Version 3}
{4.9.4.10 Calibration BICLF and ENDLF Ratio}
{4.9.4.13 Calibration Flow Rate of BPA and BPV/OSP}
{4.9.4.16 Calibration Inlet Flow Pump Nonreturn Valve RVFPE}
{4.9.4.17 Calibration Dialysate Nonreturn Valve RVDA}
{4.9.4.18 Calibration Outlet Flow Pump Nonreturn Valve RVFPA}
{4.9.4.19 Calibration Dialyser Inlet Throttle Valve DDE}
{4.9.4.20 Calibration Pressure Reducer Valve DMV}
{4.9.4.21 Gap SAKA and SAKV}
{4.9.4.23 Setting Servomotor for Disinfection Valve VD}
{5.1
Inspection Protocol for Automatic Blood Pressure Measurement ABPM}
The respective measures were executed correctly after servicing according to the
repair matrix.
BA-TE-DE08C M.KAY
Dialog SW9xx_sm_Chapter 3_1-2010.doc/pdf <100329> yymmdd
3 . R e p a i r I n s t r u c t i o n s
E x e c u t i o n P r o t o c o l
Measures According to Repair Matrix
• Conductivity (14.3 ms/cm, ±0.2)
• Temperature (37
• 15 min at UF rate 500 ml/h (3% ≈ ±4 ml)
• Protective Earth Resistance < 0.3 [Ω]:
Potential equalization bolt
Heater body (top)
Rinsing bridge (dialyser inlet and outlet)
Interior: front door (top left corner)
Interior: rear door (top left corner)
Interior: frame (rear)
Interior: housing cover (top left)
Monitor (one of the screws in the housing frame)
• Equipment Leakage Current ≤ 0.5 [mA]:
• Patient Leakage Current < 10 [µA] AC:
........................................... [mS/cm]
.................................................... [
o
C, -1.5 +0.5)
.................................................... [ml]
..................................................... [Ω]
.................................................. [mA]
................................................... [µA]
Name Service Technician:
.............................................................................
.............................................................................
Date / Signature
1 / 2 0 1 0
Measurement Values/
NA
Executed Measures
!
executed correctly
!
executed correctly
!
executed correctly
!
o
C]
!
!
executed correctly
!
(note highest value)
!
executed correctly
!
executed correctly
Please use the repair matrix
for the necessary tests and
calibrations.
B. Braun Avitum AG
3 - 107
OK
!
!
!
!
!
!
!
!
!
