B. Braun Dialog+ Service Manual page 303

+
Dialog
SW 9.xx
Calibration Point 30
Calibration Point 38
Calibration Point 50
BA-TE-DE08W M.KAY
Dialog+ SW9xx_SM_Chapter 4-3-1_1_2010.doc/pdf <110301> yymmdd
4 . T S M S e r v i c e P r o g r a m
o
C 8. Increase slowly heater power (in %) until a stable temperature value of 30
o
Note: Pay attention to the maximum fluctuation of ±0.1 °C over 10 s at
9. Press
Wait until digits are stable.
10. Enter the stable value from the temperature measurement instrument as
reference value.
11. Confirm with
12. Increase slowly heater power until a stable temperature value of 38 °C ±2
o
C
°C is displayed at the temperature measurement instrument.
Note: Pay attention to the maximum fluctuation of ±0.1 °C over 10 s at
13. Press
Wait until digits are stable.
14. Enter the stable value from the temperature measurement instrument as
reference value.
15. Confirm with
o
C 16. Increase slowly heater power until a stable temperature value of 50
o
Note: Pay attention to the maximum fluctuation of ±0.1 °C over 10 s at
The flow can be reduced slightly if the heater power (100%) is insufficient for
the last calibration point.
17. Press
Wait until digits are stable.
18. Enter the stable value from the temperature measurement instrument as
reference value.
19. Confirm with
20. Confirm and save the completed calibration procedure with
Note: The calibration data is saved only after the bit sequence 0-1-0 (for
21. Reassemble the heater inlet temperature sensor TSDE to the original
position (see previous page).
Note: Pay attention to correct flow direction of temperature sensor TSDE.
C ±2
o
C is displayed at the temperature measurement instrument.
the temperature measurement instrument.
key.
the temperature measurement instrument.
Write down the value of the heater power, because this value is
required for the calibration of the conductivity.
key.
C is displayed at the temperature measurement instrument.
the temperature measurement instrument.
key.
detailed information see 4.8.3.1 General Calibration Information).
1 / 2 0 1 0
key.
key.
key.
B. Braun Avitum AG
4 - 134
C ±2
o
key.
