B. Braun Dialog+ Service Manual page 305

+
Dialog
SW 9.xx
Calibration Temperature Sensors
Measurement of the Temperature
and the Conductivity
Measurement of the Flow
BICLF
TSBIC
T
RVB
RVK
BICP KP
Fig.: Dialysate Preparation
VDEBK1
VDABK1
VABK2
Fig.: Original Tubing UF Sub-Rack with FBK1
BA-TE-DE08W M.KAY
Dialog+ SW9xx_SM_Chapter 4-3-1_1_2010.doc/pdf <110301> yymmdd
4 . T S M S e r v i c e P r o g r a m
The temperature sensors TSBIC/TSD/TSD-S must be calibrated prior to the
calibration of the conductivity sensors BICLF/ENDLF/ENDLF-S (in menu LL
Manual Calibration, Calibration 2.5 Dialysis Temperature).
The measurement sensor for temperature and conductivity of the measurement
instrument is connected between FPE and the inlet to the balance chamber at
FBK1 (see figure).
Connect the dialyser couplings to the flow sensor.
ENDLF-S
TSD
T
ENDLF
VEBK1
VDEBK2
FBK1
VEBK2
FPE
Measurement
Instrument
RVFPE
8
T
TSD-S
FPE
FBK1
VEBK1/2
FBK2
Fig.: UF Sub-Rack with Loop-In Point for BICLF, ENDLF and
ENDLF-S Calibration
1 / 2 0 1 0
red
ml/min
o
C
blue
mS/cm
red
Measurement
Sensor
blue
Measurement
FBK2
Instrument
ml/min
o
C
mS/cm
FBK1
Measurement
red
Sensor
blue
FPE
B. Braun Avitum AG
4 - 136
D
red
D
blue
