B. Braun Dialog+ Service Manual page 146

+
Dialog
SW 9.xx
. . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . .
End of Read System Configuration...
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 3_1-2010.doc/pdf <100329> yymmdd
3 . R e p a i r I n s t r u c t i o n s 1 / 2 0 1 0
An input screen opens and the system configuration is
read from the Dialog+ hard disk drive (CFC) to the USB
stick. The Read System
automatically returns (a few seconds) to the main
menu after End of Read System Configuration... is
displayed.
3 - 84
Configuration menu
B. Braun Avitum AG
