3.6.9.8 Remove All Patient Data

F i e l d S e r v i c e U t i l i t i e s V 2 . 0 0 - S e t 0 0 0
01. Read Card Image
02. Write Card Image
03. Read Patient Diskette
04. Write Patient Diskette to Card
05. Read Patient Card
06. Write Patient Card
07. Remove All Patient Data
BP-: move cursor up BP+: move cursor down AQ: back to previous menu
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 3_1-2010.doc/pdf <100329> yymmdd
3 . R e p a i r I n s t r u c t i o n s
Remove all patient data from the FSU USB stick after service with the
utility 07. Remove All Patient Data . This will delete all patient data stored
on the FSU USB stick.
The service technician can store patient data on the USB stick by reading them
from patient cards and patient diskettes. Additionally patient data can be
copied manually to the 09_Write_Patient_Diskette_to_Card, DEFAULT
subdirectory and the 09_Write_Patient_Card, DEFAULT sub-directories. If the
patient data are not required anymore the service technician can remove them
from the USB stick in one step by using the 07 Remove All Patient Data utility.
The utility will remove all the patient data from the FSU USB stick, except the
patient card images.
The utility requires two confirmations.
First confirmation:
Are you sure?
AQ
EQ
Second confirmation:
Are you REALLY sure?
BP
BP
CRC = XXXX - OK
(Card → USB Stick)
(USB Stick → Card)
(Diskette → USB Stick)
(USB Stick → Card)
(Card → USB Stick)
(USB Stick → Card)
execute
: exit from the utility
: renewed query for confirmation
: exit from the utility
: all patient data are deleted from the FSU USB stick.
1. Press EQ
2. Press AQ
EQ:
1 / 2 0 1 0
to execute the utility.
to skip to the previous menu.
B. Braun Avitum AG
3 - 81
