4.4.1 Legend Service Overview in
Therapy
BA-TE-DE08C M.KAY
Dialog+ SW9xx_SM_Chapter 4-1-1_1-2010.doc/pdf <110301> yymmdd
4 . T S M S e r v i c e P r o g r a m
ACT INF_S: Actual infusion supervisor (not applicable)
B24V_S: 24 V cut-off blood side supervisor (HP, BPA, BPV)
BAG: Bag weight (not applicable)
BAG_S: Bag weight supervisor (not applicable)
BIC_SS: Bicarbonate rinsing connector sensor
BICLF: Bicarbonate conductivity
BICP: Bicarbonate pump
BICP_S: Bicarbonate pump supervisor
BIC-RATIO: Bicarbonate ratio
BIC-RATIO_S: Bicarbonate ratio supervisor
BKUS: BIC cartridge holder lower switch
BKUS_S: BIC cartridge holder lower switch supervisor
BL: Blood leak detector
BL_S: Blood leak detector supervisor
BOLUS_VOL: Bolus volume
BOLUS_VOL_S: Bolus volume supervisor
BPA: Arterial blood pump
BPA_S: Arterial blood pump supervisor
BPV: Venous blood pump
BPV_S: Venous blood pump supervisor
DBI VER: DBI version
D24V_S: 24 V cut-off dialysate side supervisor (VDA, VDE)
DF: Remaining time for DF
ENDLF: End conductivity
ENDLF_S: End conductivity supervisor
END-RATIO: End ratio
END-RATIO_S: End ratio supervisor
EP: Degassing pump
F(E)DFS: Filter recognition DF filter sensor
F(E)HDFS: Filter recognition HD filter sensor
FMS: Substitution flow measurement
FMS_S: Substitution flow low measurement supervisor
FPA: Outlet flow pump
FPE: Inlet flow pump
HDF/HF_V: HDF/HF volume
HDF/HF_V_S: HDF/HF volume supervisor
HDF: Remaining time for HDF
HEATER REL1_S: Heater relay 1 supervisor (not applicable)
HEATER REL2_S: Heater relay 2 supervisor (not applicable)
HP: Heparin pump
INF LEAK_S: Infusion leakage supervisor (not applicable)
K_SS: Concentrate rinsing connector sensor
KP: Concentrate pump
KP_S: Concentrate pump supervisor
LAFSO: Top air separator level sensor
LAFSU: Bottom air separator level sensor
LEFT LED_S: Left LED from OSD
LLC: Low level controller
LLS: Low level supervisor
LS CURRENTS_S: Loudspeaker current supervisor
LS PULSE_S: Loudspeaker pulse supervisor
MSBK1: Membrane position sensor balance chamber 1
MSBK2: Membrane position sensor balance chamber 2
NSVB: Level sensors upline tank
