B. Braun Dialog+ Service Manual page 114

+
Dialog
SW 9.xx
[EQ]
[AQ]
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 3_1-2010.doc/pdf <100329> yymmdd
3 . R e p a i r I n s t r u c t i o n s
The following menu appears after the motherboard and the memory type were selected.
If you have any important files, SAVE them before the installation!
TRENDS of previous treatments will be lost too, save them before
the installation if they are needed in the future!
If you want to CONTINUE the Installation
press Y or y and <CR> if keyboard is used
If you want to CANCEL the installation, press N or n and <CR>
on keyboard or any other hardware key!
Press to confirm and proceed with the installation of the software.
Press if you want to terminate the installation of the software.
....
End of Dialog/TLC
The Dialog/TLC SW INSTALLATION has been completed.
The Dialog/TLC uses......................
Don't forget to set the operation mode switch to TSM mode (2) and check
in TSM all subsystems' version number.
Switch the power OFF and REMOVE the USB stick before starting the Dialog...
The TLC software was installed successfully.
*** WARNING ! ***
otherwise
press the EQ hardware key!
SW INSTALLATION.
.......................
1 / 2 0 1 0 3 - 52
B. Braun Avitum AG
