B. Braun Dialog+ Service Manual page 77

+
Dialog
SW 9.xx
1275x
12. VEBK test
FPE = 800 ml/min
FPA = 500 ml/min
Valve Status:
VEBK1/2, VABK1/2 --------------------- closed
VDEBK1/2, VDABK1/2 ----------------- opened
VBP, VDE, VDA ------------------------ opened
Test timeout 60 s or wait for inversion of
LLS_SELFTESTBIT from LLS
1280x
13. Pressure reduction
FPE = 500 ml/min
FPA = 500 ml/min
Valve Status:
VEBK1/2, VDEBK1/2 ------------------- opened
VABK1/2, VDABK1/2------------------- opened
VBP, VDA, VDE ------------------------ opened
Timeout 60 s
14. 1299 Completed
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 3_1-2010.doc/pdf <100329> yymmdd
3 . R e p a i r I n s t r u c t i o n s
Start condition for the test (5 s):
1. Correct valve position
2. UFP stopped (UF rate < 500 ml/h)
3. +300 mmHg < PDA < +450 mmHg
Test 10 s,
max. deviation ∆PDA < 25 mmHg,
Acknowledge with inversion of LLS_SELFTESTBIT
1 / 2 0 1 0 3 - 15
12151 –
12161
12162 –
12181
12182
12183
12000
B. Braun Avitum AG
