W o r k i n g T i m e C o u n t e r
F R E E M E M O R Y
L L C / S & T L C A l a r m W i n d o w
L L C M e s s a g e W i n d o w
BA-TE-DE08C M.KAY
Dialog+ SW9xx_SM_Chapter 4-1-1_1-2010.doc/pdf <110301> yymmdd
4 . T S M S e r v i c e P r o g r a m
VDFF_S: DF filter valve supervisor
VEBK1_S: Inlet valve balance chamber 1 supervisor
VEBK2_S: Inlet valve balance chamber 2 supervisor
VLA: Air separator valve
VSAA: Substitution outlet valve
VSAA_S: Substitution outlet valve supervisor
VSAE: Substitution inlet valve
VSAE_S: Substitution inlet valve supervisor
VSB: Substitution bypass valve
VSB_S: Substitution bypass valve supervisor
VVB: Upline tank valve
VVBE: Upline tank inlet valve
VZ: Circulation valve
Working time counter (WTC)
bioLogic RR 0ption
b i o L o g i c R R
The low level controller alarms are displayed in a hexadecimal format. The
L L C A L A R M
corresponding bit alarms are shown in the LLC alarm window.
The low level supervisor alarms are displayed in a hexadecimal format. The
L L S A L A R M
corresponding bit alarms are shown in the LLS alarm window.
L L C M E S S A G E The LLC messages are displayed in a hexadecimal format. The corresponding bit
messages are shown in the message window.
Free RAM memory (DIMM/SIMM).
• L ow level controller alarm text W i n d o w messages according to the LLC
• L ow level supervisor alarm text W i n d o w messages according to the LLS
• Top level controller alarm messages W i n d o w according to the TLC hex
LLC text messages according to the LLC message hex numbers from LLC
message window.
hex numbers from the LLC alarm window.
hex numbers from the LLS alarm window.
numbers from the TLC alarm window.
