HDF Online Board HOB
Fig. : HDF Online Board
2.8.1
Legend HDF Online Board
P1: Sensors: PSABFS, PSAUS, PSPOSS, FEHDFS, FEDFFS
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 2_1-2010.doc/pdf <100329> yymmdd
2 . T e c h n i c a l System Description
P4
P1
U2
U5
P4: Valves VBE, VDFF, VSAA, VSAE, VSB
