Card Reader Read/Write Utilities

3.6.9.1 Select Menu of Card Reader
Commands
F i e l d S e r v i c e U t i l i t i e s V 2 . 0 0 - S e t M S T
01. Set System Version Number
02. Set Working Time Counter (WTC)
03. Kill Masterboot Record
04. Write Languages
05. Write Calibration Data
06. Write System Configuration
07. Undo Last Written
08. USB Stick Self Test

09. Select Menu of Card Reader Commands

10. Read System Configuration
11. Read Calibration Data
12. Read All Trends
13. Read Screenshots
14. Get Error (ErrorDisk)
BP-: move cursor up BP+: move cursor down AQ: exit – see Important Note EQ: execute
Important Note: To prevent the corruption of USB stick, before removing it,
please press AQ then follow the instructions on the screen!
BA-TE-DE08C M.KAY
Dialog+ SW9xx_sm_Chapter 3_1-2010.doc/pdf <100329> yymmdd
3 . R e p a i r I n s t r u c t i o n s
The group of read and write utilities for the card reader is used:
•
to read data from a card or diskette and to write them to a USB stick
•
to read data from a USB stick and to write them to a card
•
All card reader utilities are available in a sub-menu.
Select the 09. Select Menu of Card Reader Commands to open the sub-menu for
the card reader utilities.
CRC = XXXX - OK
(Dialog+ Hard Disk)
(USB Stick → Dialog+ Hard Disk)
(USB Stick → Dialog+ Hard Disk)
(USB Stick → Dialog+ Hard Disk)
(USB Stick → Dialog+ Hard Disk)
(Dialog+ Hard Disk → USB Stick)
(Dialog+ Hard Disk → USB Stick)
(Dialog+ Hard Disk → USB Stick)
(Dialog+ Hard Disk → USB Stick)
(Dialog+ Hard Disk → USB Stick)
1 / 2 0 1 0
1. Press the BP hardware key and move the cursor
down to select the utility:
09. Select Menu of Card Reader Commands.
2. Press the EQ hardware key to execute the
utility.
