U3022AE10
Control Lines
Setting the Control Lines with Address and Data Values
This section describes how to control the rear panel DUT control lines.
The following control feature will function only while the PNA is in its Standalone
Mode.
Setting the PNA to Standalone Mode
1. Select Utility > System > Configure > Multiport Capability -OR-
As described in
<address>.<data> values are determined in a similar manner, with the following
exceptions:
•
•
Table 14
Test Set DUT Control Address and Data Logic Table
<Address>
112
112
112
112
112
112
112
112
112
112
58
(Instrument > Setup > External Hardware > Multiport > Multiport Configuration...).
In the dialog box, select Restart as a standalone PNA > OK.
"Setting the Test Port Paths with Address and Data" on page
Table 16 will be used.
The <address> value is always = 112
<Data>
Description
0
ALL DUT Control Lines set to logic high or connected to Pin 13
255
ALL DUT Control Lines set to logic high or connected to Pin 14
1
DUT Control Line 1 set to logic low or connected to Pin 14
2
DUT Control Line 2 set to logic low or connected to Pin 14
4
DUT Control Line 3 set to logic low or connected to Pin 14
8
DUT Control Line 4 set to logic low or connected to Pin 14
16
DUT Control Line 5 set to logic low or connected to Pin 14
32
DUT Control Line 6 set to logic low or connected to Pin 14
64
DUT Control Line 7 set to logic low or connected to Pin 14
128
DUT Control Line 8 set to logic low or connected to Pin 14
Keysight U3022AE10 User's and Service Guide
52, the
Line/Pin
1-8
1-8
1
2
3
4
5
6
7
8
