U3022AE10
General Specifications

Environmental Requirements

Refer to your network analyzer's standard documentation for environmental
requirements.
The test set complies with all applicable safety and regulatory requirements for the
intended location of use.

Equipment Heating and Cooling

If necessary, install air conditioning and heating to maintain the ambient temperature
within the appropriate range.
Ventilation Requirements: When installing the instrument in a cabinet, the
convection into and out of the instrument must not be restricted. The ambient
temperature (outside the cabinet) must be less than the maximum operating
temperature of the instrument by 4 °C for every 100 watts dissipated in the cabinet.
If the total power dissipated in the cabinet is greater than 800 watts, forced
convection must be used.
Required Cond itions for Accuracy Enhanced Measurements
Accuracy–enhanced (error–corrected) measurements require the ambient
temperature of the analyzer and test set to be maintained within ± 1 °C of the
ambient temperature at calibration.

Dimensions and Space Requirements

Standard installation of the test set and analyzer includes configuration and
installation on a customer provided lab bench or table top of adequate size and
strength. For weight, dimensions and space requirements, refer to the network
analyzer documentation that is used to configure the test set.
The network analyzer is heavy. It is recommended that two individuals, or a
mechanical lift be used to lift or transport the instrument.
Table 4
Instrument Dimensions
Model
U3022AE10
Keysight U3022AE10 User's and Service Guide
Pressure Altitude (Operation)
3,000 meters (~10,000 feet)
The instrument can safely operate in a relative humidity of 80% for temperatures
to 31 degrees C, decreasing linearly to 50% relative humidity at 40 degrees C.
Weight
Height
11.4 kg
19.1 cm
(25 lb)
(7.5 in)
Wid th
Depth
42.5 cm
43.2 cm
(16.7 in)
(17 in)
15
