Control Lines

Control Lines
The 15 pin female D-Sub connector on the front panel provides 8 latched data lines
that can be used to control your device under test (DUT). The lines can be controlled
with the Multiport External Test Set control, or Test Set I/O commands. Refer to
"External Test Set Control Feature" on page 38
Address and Data Values" on page
specifications.
The output voltage of the lines can be from the internal adjustable voltage source
(+2 to +5 Vdc), or an external DC power supply depending on how the connection to
the control line is configured. When using an external power supply a positive or
negative voltage can be used. Refer to
line pin location and description. Refer to
page 56
Table 12
54
and "External Voltage Supply Configuration" on page 57
DUT Control Specifications
Item
Connector Type
Max Output Line Current
Control Line DC resistance
Voltage Range:
Positive Input
Negative Input
Internal Variable Voltage
and "Setting the Control Lines with
58. See Table 12 below for DUT control line
Figure 46 and Table 13 on page 55
"Internal Voltage Supply Configuration" on
Specifications
D-Sub, 15–pin female
100 mA (each line)
< 10 Ω (each line)
0 to +5 V
–5 to 0 V
+2 to +5 V
Keysight U3022AE10 User's and Service Guide
for control
for configurations.
