Front and Rear Panel Features

Front and Rear Panel Features
Figure 4 U3022AE10 Front Panel
Active
LED
Standby Switch
Test Ports 3.5 mm Port 3 - 12
(male)
Test Port Status An illuminated LED indicates an active port in Source or Receiver mode. On the front
LEDs
panel "S" indicates Source test ports and "R" indicates Receiver test ports.
•
Access Ports – SMA
•
Bulkhead (female)
•
•
•
A threaded terminal post for connecting the test set to a conductive object, cabinet
Chassis Ground
or structure to ensure a common potential and reduce leakage current in a system.
Requires an English 1/4-20 thread nut (2950-0004) and lock washer (2190-0067).
For further information pertaining to control lines and voltage adjustments see
Control Lines and
"Control Lines" on page
Voltage Ad just
The switch is only a Standby switch, not a AC line power switch.The main power cord
Stand by Switch
can be used as the system disconnecting device. It disconnects the mains circuits
from the mains supply.
When the Test Set is connected and addressed by a PNA-X, the LED is ON
Active LED
(illuminated). The LED is OFF (not illuminated) when the Test Set is in Standby, or
not addressed by the PNA-X.
When the two Test Sets are connected together, as in the multi-Test Set system, the first Test
Set connected to the PNA-X will never have an "ON" Active LED. Instead, the last Test Set in
the I/O cable chain will be the Test Set showing the "Active LED" status for all.
18
Test Ports 3 to 12
Control Lines
CPLR ARM
SOURCE OUT
CPLR ARM
A IN
B IN
54.
Test Port Status LEDs
Voltage Adjust
Keysight U3022AE10 User's and Service Guide
Access Ports (1 of 2)
Chassis Ground
