U3022AE10
Description
Description
The U3022AE10 is a Multiport Test Set designed to be configured with a 2 or 4-Port
PNA, PNA-L or PNA-X for a 12 or 14-Port network analyzer measurement system.
•
•
•
The network analyzers will be referred to throughout this document as the PNA,
PNA-L or PNA-X. Analyzer will be used for general information that pertains to all
of the network analyzers. The U3022AE10 will be referred to as the test set.
The "B" Model analyzers have the darker Keysight color format. The Test Set color
format has changed to match this Keysight color.
Verifying the Shipment
To verify the contents shipped with your product, refer to the "Box Content List"
included with the shipment.
Inspect the shipping container. If the container or packing material is damaged, it
should be kept until the contents of the shipment have been checked mechanically
and electrically. If there is physical damage refer to
Keep the damaged shipping materials (if any) for inspection by the carrier and a
Keysight Technologies representative.
Measurement Application Note
Low Loss DUT Measurements
Low loss trace ripple is a product of RF switch repeatability and calibration technique. Low insertion loss
measurements may exhibit uncertainty ripple residing on the measurement response. Due to a different
number of RF switches in each test port signal path, the maximum cumulative switch repeatability you may
experience for a system test port is indicated in Table 1 below.
Table 1
Test Port Repeatability Maximums (dB)
Test Port
1 - 12
Switch Configuration Command Speed
When writing address and data values to the test set directly, include a 15 ms wait before issuing
another address and data set. The delay of 15 ms is required for the test set internal switches to settle.
Failure to add the delay could cause the test set internal switches to stick or cause intermittent failures.
10
10 test ports (3.5 mm male connectors)
Low Loss Mechanical RF switching
Frequency Range of Operation:
— 300 kHz - 20 GHz (Standard Opt 700)
— 10 MHz - 20 GHz (Opt 001 or 002)
— 300 kHz - 26.5 GHz (Opt 026)
— Test Set I/O interface for operational control. An external personal computer
is not required.
300 KHz - 26.5 GHz
0.06
"Contacting Keysight" on page
Keysight U3022AE10 User's and Service Guide
94.
